Ultrasonic sensor with aluminum housing and IP68 rating CUI CUSA-TR65-065-2200-TH68 featuring 40 kHz frequency
Ultrasonic sensor with aluminum housing and IP68 rating CUI CUSA-TR65-065-2200-TH68 featuring 40 kHz frequency
Ultrasonic sensor with aluminum housing and IP68 rating CUI CUSA-TR65-065-2200-TH68 featuring 40 kHz frequency
Ultrasonic sensor with aluminum housing and IP68 rating CUI CUSA-TR65-065-2200-TH68 featuring 40 kHz frequency
Specifications
Description :
Ultrasonic Receivers, Transmitters RoHS
Mfr. Part # :
CUSA-TR65-065-2200-TH68
Model Number :
CUSA-TR65-065-2200-TH68
Description

Product Overview

The CUI DEVICES CUSA-TR65-065-2200-TH68 is an ultrasonic sensor featuring an aluminum can construction and IP68 rating. This combination unit integrates both receiver and transmitter functionalities and is designed for through-hole mounting. It operates at 40 kHz and offers a detectable range of up to 6.5 meters.

Product Attributes

  • Brand: CUI DEVICES
  • Model: CUSA-TR65-065-2200-TH68
  • Material: Aluminum (sensor housing), Brass with tin plating (terminal pins)
  • Certifications: RoHS, IP68

Technical Specifications

ParameterConditions/DescriptionMinTypMaxUnits
Transmitter/Receiver Operating Voltageat 40 kHz150Vp-p
Frequency38.54041.5kHz
Echo Sensitivityat 1 m120mV
Sound Pressure Levelat 10 V, 30 cm, sine wave100dB
Directivity Horizontal Angleat -6 dB105120degree
Directivity Vertical Angleat -6 dB5065degree
Capacitanceat 1 kHz1,7602,2002,640pF
Detectable Range0.46.5m
Response Time1.8ms
Impedance3,000
Dimensions14 x 9.0mm
Weight2.92g
Operating Temperature-4080C
Storage Temperature-4085C
SolderabilityWave Soldering Max260C
SolderabilityPreheat0100C
SolderabilitySoak Time10-15s
SolderabilityCool Down100C
