Optical encoder module Broadcom HEDS-9040J00 featuring two channel quadrature output and index pulse for high volume
Optical encoder module Broadcom HEDS-9040J00 featuring two channel quadrature output and index pulse for high volume
Optical encoder module Broadcom HEDS-9040J00 featuring two channel quadrature output and index pulse for high volume
Optical encoder module Broadcom HEDS-9040J00 featuring two channel quadrature output and index pulse for high volume
Specifications
Description :
Through Hole Specialized Sensors RoHS
Mfr. Part # :
HEDS-9040#J00
Model Number :
HEDS-9040#J00
Package :
Through Hole
Description

Product Overview

The HEDS-9040 and HEDS-9140 are three-channel optical incremental encoder modules designed to detect rotary position when used with a codewheel. These low-cost modules offer high performance with a highly collimated light source and a unique photodetector array. They provide two-channel quadrature outputs with an index pulse, suitable for high-volume applications requiring sophisticated motion control detection.

Product Attributes

  • Brand: Avago Technologies (implied by datasheet context)
  • Origin: Not specified
  • Material: Not specified
  • Color: Not specified
  • Certifications: Not specified

Technical Specifications

ModelResolutionOperating TemperatureSupply VoltageOutput TypeCodewheel Compatibility
HEDS-9040Up to 2000 CPR-40C to 100CSingle 5 VTwo channel quadrature output with index pulse, TTL compatibleHEDX-614X (Optical Radius: 23.36 mm)
HEDS-9140Up to 2000 CPR-40C to 100CSingle 5 VTwo channel quadrature output with index pulse, TTL compatibleHEDx-5x4x (Optical Radius: 11.00 mm)

Applications: Printers, plotters, tape drives, industrial and factory automation equipment.

Note: Avago Technologies encoders are not recommended for use in safety-critical applications (e.g., ABS braking systems, power steering, life support systems, critical care medical equipment).


2508211638_Broadcom-HEDS-9040-J00_C22443376.pdf
