Endress Hauser FMU40 Ultrasonic Level Transmitter 2-Wire HART
Endress Hauser FMU40 Ultrasonic Level Transmitter 2-Wire HART
Endress Hauser FMU40 Ultrasonic Level Transmitter 2-Wire HART
Endress Hauser FMU40 Ultrasonic Level Transmitter 2-Wire HART
Specifications
Brand Name :
E+H
Model Number :
FMU40-ANB2A4
Certification :
CE
Place of Origin :
DE
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
100pcs per month
Delivery Time :
8-10 weeks
Packaging Details :
Original packaging
Measuring principle :
Ultrasonic
Characteristic / Application :
Compact ultrasonic transmitter
Supply / Communication :
2-wire HART
Accuracy :
+/- 2 mm or +/- 0.2 % of set measuring range
Ambient temperature :
-40 °C ... 80 °C (-40 °F ... 176 °F)
Communication :
4...20 mA HART
Description

E+H Ultrasonic level meter FMU40-ANB2A4

The Prosonic FMU40 sensor is suited for non-contact level measurement in fluids, pastes, coarse bulk material and flow measurement in open channels or at weirs. The two-wire or four-wire compact transmitter can be used in applications with storage tanks, agitators, on stockpiles and conveyor belts. The envelope curve can be shown on the on-site display for simple diagnosis. Linearization function (up to 32 points) for conversion of the measured value into any unit of length, volume or flow rate.

Two-wire or four-wire instrument for continuous non-contact level and flow measurement.


Process connection: Thread

Temperature: -40 to +80°C (-40 to +176°F)

Pressure: +0.7 to +3bar (+10 to +44psi)

Maximum measuring distance: Liquids 5m (16ft), Solids 2m (16ft)

Blocking distance: Liquids and Solids 0.25m (0.8ft)

International explosion protection certificates


Specifications




Measuring principle

 Ultrasonic

Characteristic / Application

 Compact ultrasonic transmitter

Supply / Communication

 2-wire HART

Accuracy

 +/- 2 mm or +/- 0.2 % of set measuring range

Ambient temperature

 -40 °C ... 80 °C
(-40 °F ... 176 °F)

Process temperature

 -40 °C ... 80 °C
(-40 °F ... 176 °F)

Process pressure / max. overpressure limit

 0.7 bar ... 3 bar abs
(10 psi ... 44 psi)

Main wetted parts

 PVDF

Process connection

 G / NPT 1 1/2"

Blocking distance

 0.25 m (0.8 ft)

Max. measurement distance

 Liquids: 5 m (16 ft),
Solids: 2 m (6.6 ft)

Communication

 4...20 mA HART

Certificates / Approvals

 ATEX, FM, CSA, IEC, INMETRO, NEPSI

Application limits

 For higher resistance:
FMU42/FDU9x
Foam / high turbulence possible:
FMU41/FDU91
Fast filling and discharging rate:
FMU90 + FDU9x
Level limit detection:
FMU90 + FDU9x
