Red LED Industrial Ultrasonic Sensors NPN PNP Switching Output NO/NC IP67
Red LED Industrial Ultrasonic Sensors NPN PNP Switching Output NO/NC IP67
Red LED Industrial Ultrasonic Sensors NPN PNP Switching Output NO/NC IP67
Red LED Industrial Ultrasonic Sensors NPN PNP Switching Output NO/NC IP67
Specifications
Brand Name :
KRONZ
Model Number :
U18-D300N(P)2T-R00A
Certification :
CE
Place of Origin :
Guangdong, China
MOQ :
10 pieces
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000 pieces per month
Delivery Time :
5-8 working days
Packaging Details :
Polybag packing
Detection range :
30-300mm
Blind zone :
0-30mm
Repeatability :
±0.15% F.S.
Response time :
22ms
Switching hysteresis :
2mm
Switching frequency :
45Hz
Description

Ultrasonic Sensor NPN PNP Switching Output NO/NC 30-300mm Red LED IP67

Product Description

Main Feature:
▶ M18 installation threaded sleeve
▶ Easy to instal

Basic Feature:
▶ 1 pc npn or pnp switching output
▶ Support digital RS485, modbus-rut standard protocol communication
▶ Analog voltage output 0-10V or analog current output 4-20 mA
▶ Implementing detection distance learning function through gray lines
▶ Temperature compensation
▶ Standard operating voltage DC 10-30V

Model U18-D300N(P)2T-R00A
Dection range 30-300mm
Blind zone 0-30mm
Resolution 0.1mm
Repeatability ±0.15%F.S.
Accuracy ±1%(built-in temperature drift compensation)
Response time 22ms
Switching hysteresis 2mm
Switching frequency 45Hz
Initialization time ＜ 500ms
Supply voltage 10-30V DC,reverse-polarity protection
Red LED no object detected:Lights up, teaching-in when no object detected:Flashes
Green LED object detected:Lights up, teaching-in when object detected:Flashes
Overcurrent protection 200mA,Red LED and Green LED flashing at the same time
Load impedance I/ ＜ 300 Ohm,U/ ＞ 1k Ohm
No-load current ≤30mA
Input type teach-in and synchronization
Material Copper nikel-plated,plastic fittings,glass epoxy resin.
Enclosure rating IP67
Connection type 5pin, M12 connector
Ambient temperature -25℃ ~+70℃(248~343K)
Storage temperature -40℃ ~+85℃(233~358K)
Weight 35g
Output type N2: 1 npn switching output NO/NC
P2: 1 pnp switching output NO/NC
Dimensional drawing Red LED Industrial Ultrasonic Sensors NPN PNP Switching Output NO/NC IP67
