60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight
60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight
60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight
60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight
60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight
60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight
Specifications
Brand Name :
KRONZ
Model Number :
U18-D1000UT-R00A
Place of Origin :
Guangdong, China
Certification :
CE
MOQ :
1
Price :
Negotiable
Packaging Details :
Polybag packing
Delivery Time :
5-8 working days
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pieces per month
Detection Range :
60-1000mm
Green LED :
Object Detected:Lights Up, Teaching-in When Object Detected:Flashes
Output Type R4 :
1 Analog Voltage Output 0-10V, Up/down
Material :
Copper Nikel-plated,plastic Fittings,glass Epoxy Resin.
Accuracy :
±1%(built-in Temperature Drift Compensation)
Weight :
38g
Repeatability :
±0.15%F.S.
Description

The Industrial Ultrasonic Sensors feature a unique dual LED indicator system for easy status monitoring. When an object is detected within the sensing range, the green LED lights up, providing a clear visual confirmation. Additionally, during the teaching-in process, the green LED flashes to indicate successful detection setup. On the other hand, when no object is detected, the red LED illuminates, alerting operators to the absence of objects. The red LED also flashes during the teaching-in process for no object detection.

Features:

  • Product Name: Industrial Ultrasonic Sensors
  • Output Type I: 1 Analog Voltage Output 0-10V, Up/down
  • Accuracy: ±1% (built-in Temperature Drift Compensation)
  • Response Time: 52ms
  • Red LED: No Object Detected: Lights Up, Teaching-in When No Object Detected: Flashes
60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight

Technical Parameters:

Repeatability ±0.15%F.S.
Ambient Temperature -25℃ ~+70℃ (248~343K)
Response Time 52ms
Resolution 0.17mm
Analog Voltage Output 0-10V Up/down
Enclosure Rating IP67
Accuracy ±1% (built-in Temperature Drift Compensation)
Output Type U 1 Analog Voltage Output 0-10V, Up/down
No-load current ≤30mA
Blind Zone 0-60mm

Applications:

KRONZ Industrial Ultrasonic Sensors are versatile and reliable devices suitable for a wide range of product application occasions and scenarios. With a brand name of KRONZ and originating from Guangdong, China, these sensors come with a CE certification, ensuring high quality and compliance with European standards.

The Industrial Ultrasonic Sensors offer precise measurements with a resolution of 0.17mm, making them ideal for applications requiring accuracy and consistency. The Analog Current Output feature, with a range of 4-20mA Up/down, allows for easy integration into various industrial systems.

60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight60 - 1000mm Industrial Ultrasonic Detection Sensor Up / Down Output Type 38g Weight
