Big Capacity 2 Deck Floor Orbital Laboratory Shaker DFS-901
Big Capacity 2 Deck Floor Orbital Laboratory Shaker DFS-901
Specifications
Speed :
30-300RPM
Display :
LCD touch screen
Brand Name :
Senova
Model Number :
DFS-901
Certification :
CE
Place of Origin :
China
MOQ :
1unit
Price :
Available upon request
Payment Terms :
T/T
Supply Ability :
100 units
Delivery Time :
5-20 working days
Packaging Details :
plywood case
Power Supply :
220V/50Hz, 220V/60Hz, 110V/60Hz
Orbit :
50mm
Keyword :
Orbital Laboratory Shaker
Sample Capacity :
1000mlx48,500mlx70,or,250mlx108
Description
Big Capacity 2-deck Floor Orbital Laboratory Shaker DFS-901
Main Features

1. Adaptive P.I.D. microprocessor responds to changing experimental needs

2. Protective steel enclosure suitable for diverse laboratory environments

3. User-configurable 7” touch interface with colour-coded displays

4. Variable shaking dynamics through advanced servo technology

5. Flexible 30-segment programming for customized protocol development

6. Autonomous operation with scheduling and recovery functions

7. Adaptive memory system learns and replicates successful parameters

8. Multi-layer monitoring with visual and audible alert systems

9. Self-contained electrical protection maintains laboratory uptime

10. Durable alloy construction withstands frequent protocol changes

11. Precision-engineered bearings support varied shaking parameters

12. Gentle initiation sequence preserves sensitive biological samples

13. Proactive protection against equipment stress conditions

14. Accessible emergency controls during programmed operations

15. Configurable platform arrangements for experimental flexibility

16. Quick-change clamping system for rapid protocol switching

17. Experimental data capture through digital interfaces

18. Adaptable to various sample formats with specialized racks

Technical Data
Flask specifications DFS-901
Max. Capacity (Standard: 1 size )
Flask Clamp(PCS) 250ml 108
500ml 70
1000ml 48
Model DFS-901
Control PID
Display 7” Colour LCD with Touch Screen
Program Control 30 segments (user programmable)
Safety Protection Emergent stop button, hardware interlock, software interlock
Auxiliary Function Monitoring timer, Independent over-speed acoustic/visual alarm, short circuit,
independent current leakage & over-load protection,curve data log & storage,count-down timer
Convection Mode Natural Convection
Shaking Mode Orbital
Drive Single-shaft 5-dimesions drive
Working Environment 15℃-35℃
Timing Range 0-9999 Hr or 0-9999 Min
Speed Range(rpm) 30-300
Speed Accuracy ±1rpm
Orbit Φ50mm
Platform Size(mm) 840x620
Platform Qty. (PCS) 2
Flask Load Capacity 1000mlx48,500mlx70,or,250mlx108
N.W./G.W. (Kg) 340/383
Overall Dimensions(LxWxH,mm) 900x674x790
Packing List(LxWxH,cm) 108x80x103 135x92x109
Power 250W 250W
Power Supply AC 200-240V/50-60Hz. Optional: AC110V/60Hz
Exterior Powder Coated Steel Housing
Big Capacity 2 Deck Floor Orbital Laboratory Shaker DFS-901Big Capacity 2 Deck Floor Orbital Laboratory Shaker DFS-901Big Capacity 2 Deck Floor Orbital Laboratory Shaker DFS-901Big Capacity 2 Deck Floor Orbital Laboratory Shaker DFS-901
Introduction about laboratory shaker

Central to sample processing workflows, the laboratory shaker provides automated and consistent agitation. Available as space-saving benchtop units or high-capacity floor models, it imparts motion—typically orbital—to flasks, tubes, or plates. This motion is designed to homogenize mixtures, enhance oxygenation for cell cultures, and prevent sedimentation. The reproducibility afforded by this instrument is a cornerstone of reliable scientific methodology.

The underlying principle is the application of controlled kinetic energy to achieve fluid mixing. By standardizing the agitation process, shakers eliminate a key variable. Different models cater to specific needs: general-purpose orbital shakers, gentle-action rockers, and full-featured incubator shakers for temperature-critical applications. Advancements in user interface design, such as color touchscreens and USB data export, provide researchers with greater control and documentation capabilities.

Applications are deeply integrated. Shakers are used for culturing suspension-adapted mammalian cells. They facilitate solvent extraction in natural product isolation. They are employed in staining and destaining procedures for polyacrylamide gels. Key operational attributes include a powerful motor that ensures consistent speed regardless of load distribution, a platform designed to minimize vibration transmission to the bench, and safety features like automatic shut-off upon lid opening (for enclosed models).
