Gantry Car Wash Motors - Rolling Brush & Large Vertical Brush Motor
Gantry Car Wash Motors - Rolling Brush & Large Vertical Brush Motor
Gantry Car Wash Motors - Rolling Brush & Large Vertical Brush Motor
Gantry Car Wash Motors - Rolling Brush & Large Vertical Brush Motor
Specifications
Brand Name :
SENINTER
ratio :
13：i
Certification :
CE ROHS
Torque: :
30~108N.m
Model Number :
HW80RH59
Voltage: :
230~400VAC
Place of Origin :
China
Rated Power :
250W~1000W
Speed: :
26~128rpm
Description


13:i Ratio Gear Motor | For Gantry & Tunnel Car Washers, Brake Available, Rotatable Junction Box



Description:
This gear motor is custom-made for gantry and tunnel car wash equipment. It is widely applied to drive conveyor belts, water pumps, brushes and other components in car wash systems. Featuring a gear reduction ratio of 13:i, it cuts the output speed to 1/13 of the original motor speed, fully complying with the operating speed requirements of car wash machines. Built-in brake ensures reliable motion control and improved operational safety.




Parameter Value
Model (Not shown)
Rated Output Power 180-1000W
Motor Rated Speed 1410 RPM
Rated Voltage 230 / 400 V
Rated Frequency 50 Hz/60HZ
Rated Current 19.6 ~ 4.8 A
Degree of Protection IP66
Duty Cycle S3-60%
Insulation Class Class F
Reducer Output Spee 26~128RPM
Reduction Ratio 13:i
