Rolling Brush & Large Vertical Brush Motor
Rolling Brush & Large Vertical Brush Motor
Rolling Brush & Large Vertical Brush Motor
Rolling Brush & Large Vertical Brush Motor
Specifications
Certification :
CE ROHS
Degree of Protection :
IP66
Place of Origin :
China
Brand Name :
SENINTER
Voltage :
230 / 400 VAC
Rated Frequency :
50HZ~60HZ
Reducer Output Speed :
26~128rpm
Model Number :
HW80RH63
Rated Power :
250W-750W
Ratio :
11:i
Description
11:1 Ratio Gear Motor for Gantry & Tunnel Car Wash | Rolling Brush & Large Vertical Brush


Description


This gear motor is specially designed for car wash equipment, mainly used to drive rolling brushes and large vertical brushes on gantry and tunnel car wash machines. It is also widely applied for conveyors, water pumps and other components in car wash systems.

Fitted with a 11:1 reduction gear mechanism, it perfectly meets the speed requirements of car wash equipment. Equipped with built-in brake for precise speed and position control, it greatly improves operational safety. The rotatable junction box allows flexible installation on site.Rolling Brush & Large Vertical Brush Motor
Parameter Value
Rated Output Power 250W-750W
Rated Voltage 230 / 400 V
Rated Frequency 50 Hz~60hz
Rated Current 1.96~4.8A
Degree of Protection IP66
Duty Cycle S3-60%
Insulation Class Class F
Reducer Output Speed 26~128rpm
Reduction Ratio 11:i
