Gantry Car Wash - Left Side Brush Travel Motor
Gantry Car Wash - Left Side Brush Travel Motor
Gantry Car Wash - Left Side Brush Travel Motor
Gantry Car Wash - Left Side Brush Travel Motor
Specifications
Certification :
CE ROHS
Brand Name :
SENINTER
Rated Power :
250W-750W
Gear Ratio :
52:i
Protection Level :
IP66
Frequency :
50 Hz~60Hz
Model Number :
HW80RH24
Current :
1.96~4.8A
Place of Origin :
China
Output Speed :
26~128rpm
Voltage :
220V/400VAC
Description
52:i Ratio Gear Motor for Gantry & Tunnel Car Wash Machines, With Brake & Rotatable Junction Box

Description:

This gear motor is specially designed for car wash systems, ideal for applications including gantry travel, lifting, left side brush travel, and right side brush travel. It is widely used to drive conveyor belts, water pumps, brushes and other components in car wash facilities.

Equipped with a 52:i reduction ratio, it perfectly matches the speed requirements of car wash equipment. The built-in brake enables precise motion control and improves operational safety. The junction box is rotatable for flexible installation in different working conditions.Gantry Car Wash - Left Side Brush Travel Motor

Parameter Value
Model (Not shown)
Rated Output Power 180-1000W
Motor Rated Speed 1410 RPM
Rated Voltage 230 / 400 V
Rated Frequency 50 Hz/60HZ
Rated Current 19.6 ~ 4.8 A
Degree of Protection IP66
Duty Cycle S3-60%
Insulation Class Class F
Reducer Output Spee 26~128RPM
Reduction Ratio 52:i
