50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
Specifications
Product :
Self-sticking insulation hanger pins
Base plate :
50x50mm
Pin diameter :
2.7mm 3mm
Pin length :
20mm-150mm
accessories :
insulation washer ,insulation dome cap
Usage :
exterior wall
Factory :
yes
OEM/ODM :
Support
Brand Name :
HUIHAO
Model Number :
Self-sticking insulation hanger pins
Certification :
ISO 9001-2015
Place of Origin :
China
MOQ :
10,000 PCS
Price :
USD0.02-0.1
Payment Terms :
Western Union,T/T,L/C,Paypal
Supply Ability :
300,000 pcs per 20 days
Delivery Time :
7 days
Packaging Details :
Insulation fixing pins 1. length less than 65mm,1000 pcs per carton ,64 per carton per pallet .2. length less than 120mm ,500 pcs per carton ,64 carton per pallet .3. others to be your requirement
Description
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
Product Attributes
Attribute Value
Product Self-sticking insulation hanger pins
Base plate 50x50mm
Pin diameter 2.7mm / 3mm
Pin length 20mm-150mm
Accessories Insulation washer, insulation dome cap
Usage Exterior wall
Factory Yes
OEM/ODM Supported
Product Overview

These rock wool metal stick pins are designed for easy installation of any type of insulation up to 3.5" thick on various surfaces including air ducts, metal buildings, concrete foundations, and wooden roofs. Perfect for securing fiberglass, rubber insulation blankets, or polystyrene boards.

Key Features
  • Convenient sticker backing for easy placement
  • Unique Easy-Peel adhesive backing design eliminates fumbling with release paper
  • Firm connection between pins and bases
  • Pins are soft and easy to bend for precise positioning
  • Excellent adhesion with double-sided adhesive property
Technical Specifications
Product size Pin length: 1-1/4" - 8"
Pin diameter: 12GA, 14GA
Base size: 2"x2"
Material Pin: Stainless steel, Aluminum
Base: Galvanized steel, stainless steel, aluminum
Surface treatment Galvanized, Polished
Length tolerance ±0.1mm
Supply capability 10,000 pieces/hour
Application Fixing various insulation blankets and boards
Product Images
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
Recommended Installation Method
  1. Separation temperatures: 15 to 25℃
  2. Ensure working surface is clean, dry, and free of dust, grease, or oil
  3. Impale insulation immediately and secure firmly with fastening washer
  4. Maximum adhesive strength achieved after 24 hours

These insulation fixing pins offer high penetration strength with all types of thermal insulation boards and are suitable for brick and concrete walls.

50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
Compatible Fixing Parts
  • Round type self locking washers
  • Square type self locking washers
  • Metal dome cap washers
  • Speed clips with plastic cover
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
Packing Information
Pin Length Carton Size Quantity/Carton
38MM 41CM×28CM×17CM 1000PCS
50MM-65MM 41CM×28CM×17CM 500PCS
70MM-84MM 30CM×28CM×29CM 500PCS
90MM-120MM 30CM×30CM×30CM 500PCS
130MM-160MM 30CM×30CM×35CM 500PCS
170MM-203MM 30CM×30CM×28CM 250PCS
Others Custom packing supported
50x50mm Base Plate Self Sticking Insulation Hanger Pins For Exterior Wall Insulation
