304 Stainless Steel Crimped Wire Mesh for Animal Cage or Vibrating Screen

Vibrating screen mesh is mainly used on vibrating screen machines for screening and sizing all kinds of sand, gravel, coal, stone, rock and other materials in mineral, metallurgy, quarry and other industries.
Woven vibrating screen mesh. it is the most popular and widely used type of vibrating screen mesh. It contains high tensile spring steel vibrating screen mesh, manganese steel vibrating screen mesh and stainless steel vibrating screen mesh.
Woven vibrating screen mesh has different weaving method and various edge types.

Perforated vibrating screen mesh. It is made of high tensile strength metal sheet and then punched to the round hole, square hole and hexagonal hole.
Square hole is the most frequency used type of the three. It offers the maximum open area for the screen.
Round hole supplies the minimum open area. It can be used in the places where the sizing is strictly requirements.
Hexagonal hole is the compromise of the round hole and square hole. It can be used in the places where the size is important but not strict.
Polyurethane vibrating screen mesh. It is a special structure, which contains metal steel wire inside and polyurethane surface outside. The polyurethane has great wear resistance performance, it can supply the extra wear life for the screen and save the replacement time and improve the screening efficiency.
Piano wire screen. Piano wire screen is a simple structure, which is formed by longitudinal wires, which are fixed into a metal or plastic sliding bar to keep wires in place and maintain the opening size. There is no other cross wire on the screen, so it supplies more open areas for the screen. It is widely used for screening the wet, sticky and other materials. The wire diameter and spacing between the air can be customed.
Self cleaning screen mesh. Self cleaning screen mesh has three types: W mesh, D mesh and H mesh. They all have the ability of self cleaning. It can offer effective solutions to difficult sizing and reduce the blinding and plugging.
Trommel screen mesh. Trommel screen mesh is the variation of the vibrating screen mesh. It is particularly effective on lighter, wetter materials, like mulch, topsoil and compost for more safety and high efficiency.

Specification

• Material: High tensile spring steel, manganese steel and stainless steel.
• Wire diameter: 0.71mm - 12.5mm.
• Opening size: 1mm - 100mm.
• Weaving type: Double crimped, intermediate crimped, flat top crimped, lock crimped.
• Mesh type: Square, rectangular slot, long slot.
• Surface treatment: Black or red color painted.
• Edge preparation: Plain, bent, reinforced shroud, welded shroud, bolt shroud.
• Hook type: C or U hook for 30° - 180°.
