Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh
Specifications
Brand Name :
Qijie
Place of Origin :
China
MOQ :
100pcs
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100pcs/week
Delivery Time :
15-18days
Packaging Details :
pallets
Model Number :
expanded metal mesh
Certification :
sgs
Height :
10-300mm
Hole :
Diamond, round and hexgonal shape
Length :
Less THAN 3000MM
Lwm :
12.5-200mm
Material :
Stainless Steel
Open Area :
60%
Sheet Size :
1mx2m, 4'x8' or 4'x10' or customized
Sheet Thickness :
2.0-4.0mm
Wire Gauge :
20#-6#
Description

Stainless Steel Plate Sheet Slotted Hole Expanded Metal

Ceiling aluminum mesh is a kind of decorative material that has been used more in interior decoration ceilings in recent years. From the perspective of decoration, the ceiling aluminum mesh must at least have high appreciation and practicability, and also have different users' choices.

There are many names for aluminum mesh: aluminum mesh, anodized aluminum mesh, aluminum decorative mesh, curtain wall aluminum mesh, aluminum curtain wall mesh, aluminum stretched mesh, fluorocarbon sprayed aluminum mesh, aluminum mesh, aluminum expanded mesh, aluminum oxide mesh, Exterior wall aluminum mesh, decorative aluminum mesh, ceiling aluminum mesh.
Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh

Features of ceiling aluminum mesh: high appreciation, strong practicability, strong ventilation, strong light transmission, sound absorption, simple construction, convenient and simple daily maintenance.

Application of ceiling aluminum mesh: suitable for hotel halls, railway station waiting rooms, platforms, conference halls, entertainment halls, large workshops, etc. Mechanical shearing expands the length of the original steel plate several times to dozens of times. It also increases the strength and hardness of the steel plate, and reduces its own weight, air can flow through the mesh, no waste is generated from it, and the cost is reduced

Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh

1.Material:superior quality galvanzed,stainless,aluminium and brass sheet
2.Sheet thickness:0.1-10mm
3.Width:0.2-2.4m
4.Length:0.5-5m
5.Opening shapes:round,oval,hexagonal and diamond etc.
6. SWDxLWD: 2mmx4mm~100mmx200mm
7.Application:
Expanded Metal is also named Expanded Mesh or Expanded Metal Mesh. Expanded Metal is widely in industrial, building, household railway, highway, construction, grain, mechanical maintenance, and musical facilities. road, railway, civil building, water conservancys building; The protecting, electrical equipment, window and aquatic products breed.

Specification of Expanded Metal Mesh
Sheet Thickness Opening in Width
mm		 Opening in Length
mm		 Stem Roll Width
mm		 Roll Length
mm		 Weight
kg/m2
0.5 2.5 4.5 0.5 0.5 1 1.8
0.5 10 25 0.5 0.6 2 0.73
0.6 10 25 1 0.6 2 1
0.8 10 25 1 0.6 2 1.25
1 10 25 1.1 0.6 2 1.77
1 15 40 1.5 2 4 1.85
1.2 10 25 1.1 2 4 2.21
1.2 15 40 1.5 2 4 2.3
1.5 15 40 1.5 1.8 4 2.77
1.5 23 60 2.6 2 3.6 2.77
2 18 50 2.1 2 4 3.69
2 22 60 2.6 2 4 3.69
3 40 80 3.8 2 4 5.00
4 50 100 4 2 2 11.15
4.5 50 100 5 2 2.7 11.15
5 50 100 5 1.4 2.6 12.39
6 50 100 6 2 2.5 17.35

Production process

Expanded: The expanded process is using the automatic expanded machines to cut the metal sheet in the transverse direction and at the same time stretch in length without loss the material. And then pass through a cold rolled reducing mill. During the process the length of the sheet is prolonged about 5%, but the width of the sheet remains the same.

Stainless Steel Plate Sheet Slotted Hole Expanded Metal mesh

Packaging & Shipping

1. On galvanized iron pallet and Free-fumigation wooden case with waterproof cloth
2. On galvanized iron pallet with waterproof cloth
3. Free-fumigation wooden case
4. In Free-fumigation wooden case with waterproof paper
5. In carton box
6. In roll with woven bag,the biggest width is 3000mm
7. In bulk or In bundle

Product tags

stainless steel rectangular hollow section

,

sheet metal hole

,

slotted mesh perforated metal
