Specifications
Brand Name :
KELONG
Model Number :
KL-114
Place of Origin :
CHINA
MOQ :
100
Payment Terms :
L/C, T/T
Supply Ability :
100,000 pcs /months
Delivery Time :
15
Packaging Details :
Customizable packaging
Certification :
ISO9001 / IRIS
Name :
Oring Backup Ring Seal
Advantages :
Extrusion resistance in larger gap clearance
Application :
Agricultural machinery / Forklifts
Pressure (max) bar :
600
Material :
PU
Description

KL114 - BACK-UP RING Extrusion Resistance In Larger Gap Clearance Easy Installation Can Be Used At High Pressure

K81 back-up rings are sealing elements that are generally used behind the o-ring in order to ensure system security and minimize extrusion gaps in many applications.

Advantages

• Extrusion resistance in larger gap clearance
• Easy installation
• Can be used at high pressure
• Wide range of dimensions

Area of Application

• Agricultural machinery
• Construction machinery
• Loading platforms
• Injection moulding machines
• Forklifts
• Standard industrial cylinders
KL114 Oring Backup Ring Seal Extrusion Resistant In Larger Gap Clearance
d (f7) D (H8) H L1 (+0.2/-0) L2 (+0.2/-0) O-Ring d2 MATERIAL
KL114-006 6 12 2 6.5 8.5 3.53 TPE
KL114-012 12 16 1.2 4.6 5.8 2.62 TPE
KL114-020 20 25 1.3 5.2 6.5 3 TPE
KL114-020/1 20 30 1.3 9.1 10.4 6 TPE
KL114-022 22 28 1.5 6 7.5 3.53 TPE
KL114-025 25.4 30 1.9 5.8 7.7 3 TPE
KL114-025/1 25 30 1.3 5.2 6.5 3 TPE
KL114-026 26 30 2 5.4 7.4 2.62 TPE
KL114-027 27 32 1.3 5.2 6.5 3 TPE
KL114-028 28.2 34.6 1.3 6.5 7.8 4 TPE
KL114-030 30 35 1.3 5.2 6.5 3 TPE
KL114-034 34.68 39.68 1.75 5.65 7.4 3 TPE
KL114-035 35 40 1.3 5.2 6.5 3 TPE
KL114-036 36 40.5 1.25 5.15 6.4 3 TPE
KL114-038 38 43 1.3 5.2 6.5 3 TPE
KL114-040 40 45 1.3 5.2 6.5 3 TPE
KL114-040/1 40 45 1.9 5.8 7.7 3 TPE
KL114-040/2 40 45 1.3 4.7 6 2.62 TPE
KL114-041 41 45.5 1.25 5.15 6.4 3 TPE
KL114-043 43 48 1.3 5.2 6.5 3 TPE
KL114-043/1 43 50 1.9 7.1 9 4 TPE
KL114-044 44.3 50.5 1.3 6.5 7.8 4 TPE
KL114-045 45 50 1.3 5.2 6.5 3 TPE
KL114-045/3 45 49.5 1.5 5.4 6.9 3 TPE
KL114-045/4 45 55 1.5 9.3 10.8 6 TPE
KL114-046 46 50.5 1.25 5.15 6.4 3 TPE
KL114-047/1 47 51.5 1.5 5.4 6.9 3 TPE
KL114-048 48 54 1.5 6 7.5 3.53 TPE
KL114-049 49 55 1.3 5.8 7.1 3.53 TPE
KL114-050 50 55 1.3 5.2 6.5 3 TPE
KL114-050/2 50 60 1.7 9.1 10.8 5.7 TPE
KL114-052 52 60 1.9 8.4 10.3 5 TPE
KL114-053 53.7 60 1.9 7.1 9 4 TPE
KL114-053/1 53 63 1.7 9.1 10.8 5.7 TPE
