Specifications
Brand Name :
KELONG
Model Number :
KL108
Place of Origin :
SHAANXI
MOQ :
100
Payment Terms :
L/C, T/T
Supply Ability :
100,000 pcs /months
Delivery Time :
15
Packaging Details :
Can be customized according to needs
Name :
Single Acting Rod Seals
Material :
FABRIC NBR
Pressure (max) bar :
250
Temperature (max) °C :
-30/+80
Sliding Speed (max)- m/s :
2.0
Description

KL108 Chevron rings are single acting rod seals made by water resistant fabric impregnated elastomer, specially designed for water and wateroil mixture. They are high pressure pump seals working at high pressure washers.

The rod seal is designed to ensure that pressurized fluid does not leak out of the system as the rod cycles back and forth (dynamic pressure sealing). The rod seal is the most critical seal on any type of fluid power equipment. A leaking rod seal not only reduces equipment performance, but also causes environmental issues.

Advantages

• High speeds

• Water compatibility and low swelling

• Long service life

• Adjustable housing
• High abrasion resistance

• Insensibility against shock loads and pressure peaks

• Low compression set

Area of Application

• Pressure washers

Water Resistant Single Acting Rod Seals Low Swelling With Adjustable Housing

d (f7) D (H9) H H1 C MATERIAL
KL108-024 15 24 3 5 6 FABRIC NBR
KL108-025 15 25 3 5 6 FABRIC NBR
KL108-026 18 26 3 5 6 FABRIC NBR
KL108-028 15 28 4 6.5 7 FABRIC NBR
KL108-028/1 18 28 3.5 5.5 6 FABRIC NBR
KL108028/2 18 28 4 6 6 FABRIC NBR
KL108-030 15 30 4.5 7.5 8 FABRIC NBR
KL108-030/1 16 30 4 7 8 FABRIC NBR
KL108-030/2 18 30 3.5 6 7 FABRIC NBR
KL108-030/3 20 30 3.3 5.5 6 FABRIC NBR
KL108-032 18 32 4.6 7.1 8 FABRIC NBR
KL108-032/1 20 32 4.5 6.7 7 FABRIC NBR
KL108-032/2 22 32 3.3 5.7 6 FABRIC NBR
KL108-034 18 34 4 6 8 FABRIC NBR
KL108-034/1 20 34 4.5 7.5 8 FABRIC NBR
KL108-035 20 35 4.5 7.5 8 FABRIC NBR
KL108-035/1 22 35 4.5 7 7 FABRIC NBR
KL108-035/2 24 35 4 6 7 FABRIC NBR
KL108-035/3 25 35 3.3 5.5 6 FABRIC NBR
KL108-037 25 37 3.6 6.7 7 FABRIC NBR
KL108-037/1 20 37 4.5 7.5 9 FABRIC NBR
KL108-038 22 38 3.5 8.5 8 FABRIC NBR
KL108-038/1 25 38 4.6 7 7 FABRIC NBR
KL108-038/2 28 38 4.1 6.1 6 FABRIC NBR
KL108-045 30 45 4.5 7.5 8 FABRIC NBR
KL108-048 36 48 3.5 6 7 FABRIC NBR
KL108-048/1 38 48 3.5 6 6 FABRIC NBR
KL108-050/1 40 50 3.5 6 6 FABRIC NBR
KL108-055 40 55 4.5 7.5 8 FABRIC NBR
KL108-056 36 56 6 10 9 FABRIC NBR
KL108-060 45 60 4.5 7.5 8 FABRIC NBR
KL108-060/1 50 60 3.5 5.5 6 FABRIC NBR
KL108-065 50 65 4.5 7.5 8 FABRIC NBR
KL108-065/1 55 65 3.5 5.5 6 FABRIC NBR
KL108-070 55 70 4.5 7.5 8 FABRIC NBR
KL108-076 60 76 5 8 8 FABRIC NBR
KL108-080 65 80 4.5 7.5 8 FABRIC NBR
