Specifications
Brand Name :
Kelong
Model Number :
KL22
Certification :
ISO9001 / IRIS
Place of Origin :
China
Payment Terms :
L/C, T/T, Paypal
Supply Ability :
100,000 pcs /months
Delivery Time :
7-15 work days
Packaging Details :
Opp bag
Style :
Hydraulic Piston-Rod Seals
Material :
NBR
Pressure (max) bar :
150
Temperature (max) °C :
-30/+105
Sliding Speed (max)- m/s :
0.5
Application :
Forklifts / Injection moulding machines / Agricultural machinery / Standard hydraulic cylinders
Description

Piston-Rod Seal Made Elastomer Material Single Acting Sealing Element With Cut And Symmetrical Lips Structure.

KL22 piston-rod seal is an elastomer material single acting sealing element which is able to work both at piston and rod applications thanks to straight cut and symetrical lips structure. Recommend to use with backup rings above 100 bars.

Advantages

• Wide range of dimensions
• Economical sealing solution
• Good dynamic and static sealing
• Good locking feature

Area of Application

• Forklifts
• Injection moulding machines
• Agricultural machinery
• Standard hydraulic cylinders
NBR Piston Rod Seals Hydraulic Elastomer With Cut / Symmetrical Lips Structure
d(f7) dp(h11) Db(H11) D(H11) L (+0.2/-0) H C MATERIAL
KL22-003 3 7 6 5 3 NB
KL22-004 4 10 4.5 4 3 NB
KL22-005 5 12 6 5 3 NB
KL22-006 6 12 4.5 4 3 NB
KL22-006/1 6 15 6 5 4 NB
KL22-006/3 6 16 7 6 4.5 NB
KL22-007 7 15 6 5 4 NB
KL22-007/1 7.94 12.7 4 3.5 2 NB
KL22-008 8 14 4.5 4 3 NB
KL22-008/1 8 14.2 4 3.5 3 NB
KL22-008/2 8 16 4 3.5 4 NB
KL22-008/3 8 16 4.7 4.2 4 NB
KL22-008/4 8 12 4.5 4 2 NB
KL22-010 10 14 2.5 2 2 NB
KL22-010/1 10 16 4.5 4 3 NB
KL22-010/3 10 18 6 5 4 NB
KL22-010/4 10 22 7 6 5 NB
KL22-010/5 10 19 4 3.5 4 NB
KL22-010/6 10 20 4 3.5 4.5 NB
KL22-010/7 10 23 5 4.5 5 NB
KL22-012 12 18 4.5 4 3 NB
KL22-012/1 12 20 6.5 5.5 4 NB
KL22-012/3 12 22 6 5 4.5 NB
KL22-012/4 12 24 7 6 5 NB
KL22-012/5 12.5 23 4 3.5 4.5 NB
KL22-012/6 12.5 20 5 4.5 4 NB
KL22-012/7 12.5 20.3 4 3.5 4 NB
KL22-014 14 20 4.5 4 3 NB
KL22-014/1 14 20 5.3 4.8 3 NB
KL22-014/2 14 25 4 3.5 4.5 NB
KL22-015 15 22 4.5 4 3 NB
KL22-015/1 15 24 8 7 4 NB
KL22-015/2 15 25 7 6 4.5 NB
KL22-016 16 22 4.5 4 3 NB
KL22-016/1 16 22 7 6 3 NB
KL22-016/2 16 25 6 5 4 NB
KL22-016/3 16 26 6 5 4.5 NB
KL22-018 18 26 4.5 4 4 NB
KL22-018/1 18 24 4.5 4 3 NB
KL22-018/2 18 25 4.5 4 3 NB
KL22-020 20 28 4.5 4 4 NB
KL22-020/1 20 28 9 8 4 NB
KL22-020/3 20 30 9 8 4.5 NB
KL22-020/5 20 35 11 10 5.5 NB
KL22-020/6 20 32 8.5 7.5 5 NB
KL22-022 22 30 7 6 4 NB
KL22-022/1 22 35 8 7 5 NB
KL22-022/2 22 32 6 5 4.5 NB
KL22-022/3 22 28 6 5 3 NB
KL22-024 24 30 6 5 3 NB
KL22-024/1 24 32 4.5 4 4 NB
KL22-024/2 24 34 6 5 4.5 NB
KL22-025 25 33 8 7 4 NB
KL22-025/1 25 40 7 6 5.5 NB
KL22-027 27 36 7 6 4 NB
KL22-028 28 38 6 5 4.5 NB
KL22-028/2 28 52 11 10 7 NB
KL22-029 29 35 7 6 3 NB
KL22-030 30 40 10 9 4.5 NB
KL22-030/1 30 45 11 10 5.5 NB
KL22-030/2 30 55 13 12 7 NB
KL22-032 32 42 9 8 4.5 NB
KL22-032/1 32 40 8 7 4 NB
KL22-032/2 32 48 9 8 5.5 NB
KL22-032/3 32 40 4.5 4 4.5 NB
KL22-033 33 42 8 7 4 NB
KL22-035 35 45 6 5 4.5 NB
KL22-035/1 35 45 7 6 4.5 NB
KL22-035/2 35 42 6.3 5.3 4.5 NB
KL22-040 40 50 6 5 4.5 NB
KL22-040/1 40 60 11 10 7 NB
KL22-040/2 40 48 9 8 4 NB
KL22-046 46 70 13 12 7 NB
KL22-048 48 60 7 6 5 NB
KL22-048/1 48 60 8 7 5 NB
KL22-050 50 80 16 15 8 NB
KL22-050/1 50 75 13 12 7 NB
KL22-055 55 70 11 10 5.5 NB
KL22-058 58 70 7 6 5 NB
KL22-060 60 100 21 20 10 NB
KL22-061 61 73 7 6 5 NB
KL22-062 62 86 13 12 7 NB
KL22-064 64 80 9 8 5.5 NB
KL22-072 72 84 9 8 5 NB
KL22-072/1 72 84 7 6 5 NB
KL22-072/2 72 82 6 5 4.5 NB
KL22-075 75 100 13 12 7 NB
KL22-075/1 75 90 8.5 7.5 5.5 NB
KL22-080 80 100 11 10 7 NB
KL22-082 82.55 95.25 10.52 9.52 5.5 NB
KL22-130 130 150 11 10 7 NB
KL22-135 135 150 11 10 5.5 NB
KL22-220 220 250 16 15 7.5 NB
KL22-230 230 270 21 20 10 NB
KL22-290 290 330 21 20 10 NB
