Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Hydraulic Piston Rod Seals Element With Simple Groove Design
Specifications
Brand Name :
Kelong
Model Number :
KL21
Certification :
ISO9001 / IRIS
Place of Origin :
China
Payment Terms :
L/C, T/T, Paypal
Delivery Time :
7-15 work days
Packaging Details :
Opp bag
Supply Ability :
100,000 pcs /months
Style :
Hydraulic Piston Rod Seal
Material :
NBR / FABRIC NBR
Pressure (max) bar :
250
Temperature (max) °C :
-30/+105
Sliding Speed (max)- m/s :
0.5
Application :
Standard hydraulic cylinders / Mobile hydraulic cylinders / Industrial cylinders
Description

Single-Acting Sealing Element Used In Hydraulic Rod And Piston Applications With Simple Groove Design

K36 single-acting sealing element designed to be used in hydraulic rod and piston applications, is made of the fabric reinforced elastomer material to increase the pressure resistance at the bottom and elastomer material that serves as a seal at the top.

Advantages

• Very good sealing at low pressures with high preloading and elastomer material
• High extrusion and tensile strength
• Operating in heavy duty conditions
• Simple groove design

Area of Application

• Standard hydraulic cylinders
• Mobile hydraulic cylinders
• Industrial cylinders
Hydraulic Piston Rod Seals Element With Simple Groove Design
d(h9) dp(f8) Db(H10) D(H9) L (+0.2/-0) C MATERIAL
K21-004 4.76 12.7 6.35 5 NB
K21-010 10 17 6.3 5 NB
K21-010/1 10 19 6.3 5 NB
K21-012 12 20 6.3 5 NB
K21-014 14 22 6.3 5 NB
K21-014/1 14 22 7 5 NB
K21-014/2 14 22 8.5 5 NB
K21-015 15 23 6.3 5 NB
K21-016 16 24 6.3 5 NB
K21-016/1 16 24 6.5 5 NB
K21-016/2 16 24 7 5 NB
K21-018 18 26 6.3 5 NB
K21-018/1 18 24 5.2 5 NB
K21-019 19.5 27.5 8.3 5 NB
K21-020 20 28 6.3 5 NB
K21-020/1 20 26 5.5 5 NB
K21-020/2 20 27 6.5 5 NB
K21-020/3 20 28 7 5 NB
K21-020/4 20 30 8.5 5 NB
K21-020/6 20 30 8 5 NB
K21-022 22 30 6.3 5 NB
K21-022/1 22 30 6.5 5 NB
K21-022/2 22 30 7 5 NB
K21-022/3 22 32 7.3 5 NB
K21-025 25 32 6.3 5 NB
K21-025/1 25 33 6.3 5 NB
K21-025/2 25 33 6 5 NB
K21-025/3 25 35 8.3 5 NB
K21-025/5 25 35 9 5 NB
K21-025/6 25 35 6 5 NB
K21-028 28 36 6.3 5 NB
K21-028/1 28 43 11 5 NB
K21-028/2 28 35 4.5 5 NB
K21-028/3 28 36 6.4 5 NB
K21-028/4 28.57 41.27 10 5 NB
K21-030 30 38 6.3 5 NB
K21-030/1 30 38 6 5 NB
K21-030/2 30 40 6.3 5 NB
K21-030/3 30 40 7.5 5 NB
K21-030/4 30 40 7 5 NB
K21-030/5 30 50 14.5 5 NB
K21-030/6 30 38 6.4 5 NB
K21-030/7 30 37.5 6.5 5 NB
K21-031 31.75 47.62 11.6 5 NB
K21-032 32 40 6.3 5 NB
K21-032/1 32 44 12.5 5 NB
K21-035 35 43 6.3 5 NB
K21-035/1 35 45 8 5 NB
K21-035/2 35 43 6 5 NB
K21-035/3 35 50 11.5 5 NB
K21-035/4 35 43 6.5 5 NB
K21-035/5 35 43 7.3 5 NB
K21-035/6 35 45 7.5 5 NB
K21-036 36 44 6.3 5 NB
K21-036/1 36 51 11 5 NB
K21-038 38 50 9.5 5 NB
K21-038/1 38.1 50.8 12.4 5 NB
K21-040 40 48 6.3 5 NB
K21-040/1 40 50 8 5 NB
K21-040/2 40 48 8 5 NB
K21-040/3 40 50 7 5 NB
K21-040/5 40 60 14.5 5 NB
K21-040/6 40 50 11 5 NB
K21-040/7 40 48 7.3 5 NB
K21-042 42 50 6.3 5 NB
K21-045 45 53 8.5 5 NB
K21-045/1 45 55 8 5 NB
K21-045/2 45 55 10.5 5 NB
K21-045/3 45 60 11 5 NB
K21-045/4 45 57 9.5 5 NB
K21-045/5 45 65 14.5 5 NB
K21-045/6 45 53 6.3 5 NB
K21-045/8 45 60 12 5 NB
K21-046 46 56 8 5 NB
K21-048 48 60 10 5 NB
K21-048/1 48 63 11 5 NB
K21-050 50 62 9.5 5 NB
K21-050/1 50 60 7.5 5 NB
K21-050/2 50 60 8 5 NB
K21-050/3 50 60 10 5 NB
K21-050/4 50 70 14.5 5 NB
K21-055 55 65 8 5 NB
K21-055/1 55 67 10.5 5 NB
K21-055/2 55 70 10.5 5 NB
K21-055/3 55 63 8.3 5 NB
K21-056 56 66 8 5 NB
K21-056/1 56 76 14 5 NB
K21-060 60 70 8 5 NB
K21-060/1 60 70 7.5 5 NB
K21-060/2 60 72 9.5 5 NB
K21-060/3 60 80 12.5 5 NB
K21-060/4 60 72 10 5 NB
K21-060/5 60 75 13 5 NB
K21-060/6 60 80 14.5 5 NB
K21-063 63.5 82.55 14.28 5 NB
K21-065 65 73 9.6 5 NB
K21-065/1 65 77 9.6 5 NB
K21-065/2 65 85 14.5 5 NB
K21-070 70 80 7.5 5 NB
K21-070/1 70 82 9.6 5 NB
K21-070/2 70 82 9 5 NB
K21-070/3 70 90 14 5 NB
K21-070/4 70 85 8 5 NB
K21-070/5 70 80 8 5 NB
K21-070/6 70 85 12 5 NB
K21-075 75 87 9.3 5 NB
K21-075/1 75 85 8 5 NB
K21-080 80 92 9.6 5 NB
K21-080/1 80 96 10 5 NB
K21-080/2 80 92 9 5 NB
K21-080/3 80 90 8 5 NB
K21-080/4 80 100 14 5 NB
K21-085 85 97 9.6 5 NB
K21-085/1 85 110 13.5 5 NB
K21-088 88.9 101.6 10 5 NB
K21-090 90 102 9.6 5 NB
K21-090/1 90 110 12.5 5 NB
K21-100 100 115 12 7 NB
K21-100/1 100 120 14 7 NB
K21-110 110 125 12 7 NB
K21-110/1 110 130 12 7 NB
