Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Specifications
MOQ :
1 Set
Price :
1000
Place of Origin :
China
Brand Name :
Sansion
Certification :
CE/CNAS/ISO9001
Packaging Details :
Plywood Case
Payment Terms :
L/C T/T
Supply Ability :
100 Units/Month
Model NO. :
SXBTC
Max Diameter of Workpiece :
<500mm
Mass Scope of Workpiece :
<900kg
Type :
Transformer Capacity Tester
Maxcapacity :
<1000KN
Accuracy Grade :
0.5
Load Way :
Electronic Load
Loading Method :
Dynamic Load
Display :
Digital
Control :
Manual Control
Weight :
0-100Kg
Power Source :
AC220V
Oil Cylinder Position :
Without
Test Function1 :
Capacity Test
Test Function2 :
Characteristic Test
Test Function3 :
No-Load Test / No-Load Loss Test
Test Function4 :
Load Test / Load Loss Test
Test Function5 :
Short-Circuit Impedance Test
Test Function6 :
Turns Ratio (TTR)
Test Function7 :
Winding Resistance Test
Test Function8 :
Excitation Current Test
Test Function9 :
Power Loss Measurement
Test Function10 :
Vector Group Verification
Test Function11 :
Polarity Test
Transport Package :
Plywood Case
Specification :
ISO9001 SGS
Trademark :
Sansion
Origin :
China
HS Code :
9030332000
Production Capacity :
100 Units/Month
售后服务 :
Onsite and Video Call Remote Guidance
保修期 :
2 Years Free Warranty Long Life Service
Description
Product Description
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester

General Information:
We can measure a variety of distribution transformer, power transformer capacity instead of the additional extra power. It is more convenient and efficient.
Combined with the external power source, voltage, current regulator equipment etc, it can measures various transformer parameter such as no-load current, no-load loss, impedance voltage, load loss and so on.
Characteristic test of transformer, test range is wide,flexible configured.only through the simple connection to current transformer and voltage transformer, test scope can be enlarged to high-grade power transformer.
Short-circuit the terminals of cable,humanization design,with lock,easy connected to fasten units of transformation.
All results are automatically carried out relevant correction. You only need to input the related parameters (such as temperature, load adjustment coefficients etc), then the instrument can automatically calibrate such as waveform deformity correction, temperature correction, correction of non rated voltage, rated current correction,so that the accurate is much higher
Features:
√ Tailored for 10kV distribution transformers with full-spectrum testing functionalities
√ Enables energy efficiency classification for oil-immersed (S22, SH25) and dry-type (SCB18, SCBH19) transformers
√ Cutting-edge harmonic analysis with waveform and histogram visualization
√ 6-channel simultaneous AC sampling paired with digital signal processing for superior precision
√ Integrated lithium battery equipped with 3-phase sine wave inverter power (soft startup/shutdown)
√ Dual power supply modes: lithium battery or 220V AC charger with smart charging control
√ Large-size LCD screen with Chinese UI for real-time multi-parameter display
√ Data logging: 200 on-board records + USB export (Word format) plus thermal printing function
√ Compatible with external voltage/current transformers featuring adjustable transformation ratios
√ Compact structure (320mm×270mm×145mm) and lightweight build (5kg) for effortless portability
* Standard: IEC270
Specifications:
Active:
Voltage measuring range: AC 50V～850V
Current measuring range: AC 0.5A～100A
Passive:
Voltage measuring range: AC 50V～850V
Current measuring range: AC 0.5A～100A
Precision:
Voltage:±0.2%
Current:±1%
Power:±10%
Working Temperature:
-10ºC~ +40ºC
Charging source:
30kVA～65,000kVA
Volume
320mm×270mm×145mm
Company Profile
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
About Sansion
Sansion Power Electric was established in 2005, a technocrat who have rich experience of more than 20 years in R&D, manufacturing and marketing of power electrical testing products, which are widely used in the fields of power electric, railroad, energy conservation and environment protection, water conservancy, petrochemical industry, aerospace and etc.
Sansion Power Electric contains R&D department, instruments manufacturing workshop, HV workshop, sample exhibition room, HV testing laboratory, quality control department, general office, sales departments, information office and ete, now we have more than 80 employees including 20 technical engineers. We have obtained the IS09001 quality system certification and all products strictly conform to theinternational lEC and Chinese state standards.
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Certifications
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Packing & Delivery
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
Customer Visit
Transformer Capacity and Load Parameter Analyzer Transformer Capacity and Load Tester
FAQ
Q1: Is your company a sales company or a manufacturer?
A: Sansion Power Electric Co., Ltd. is an industrial and trade enterprise, with its own factory, self-produced and self-sold. We were founded in 2005 and have twenty years of production experience. Our company has reliable production lines, test rooms and R&D centers.

Q2: Whether the goods are in stock, whether they can be customized, and how long the delivery time is?
A: After the goods have been ordered, we can be made to order according to the special requirements of customers by using the latest technology. The delivery time is usually within 10 working days if there are no accidents.
Q3: Is the quality guaranteed?
A: In order to ensure quality, we use imported components in large quantities. After three times of quality inspection, the goods can be sent out, and the export is uniformly packed in non-fumigation wooden boxes.
Q4: What are the after-sales terms?
A: What are the after-sales terms?
We offer free consulting service, one year warranty, and adopt various methods such as email communication, video calls, technology door-to-door, aiming to solve any after-sales problems in a timely manner.
Q5: What are the cooperative countries or regions?
A: Products have been successfully exported to the United States, French ,Brazil, Australia, Spain, Portugal , Oman ,Russia, the Netherlands, Indonesia, Bangladesh, Saudi Arabia, Chile, Colombia, Panama, Malaysia and other countries and regions.
