Specifications
Brand Name :
AGMT
Model Number :
XY-SR210
Certification :
CE
Place of Origin :
Hefei, Anhui, China
MOQ :
One unit
Price :
26280
Payment Terms :
L/C,T/T
Supply Ability :
50 units/month
Delivery Time :
30-40 working days
Packaging Details :
Film wrapped and packed in wooden case
Name :
Pick And Place Robot
Robot HMI origin :
Korean PLC
Product capacity :
500-800 packages/hour
Voltage :
3 phase/ 380V
A axis movement :
330 degree
Application :
Beverage , Food , Carton, Drum, bag etc.
Function :
Palletizing , stacking, placing etc.
Robot gripper type :
designed according to product
Description
Low Cost Pick And Place Robot Palletizing With Factory Layout Design
AGMT XY-SR series palletizing robot is a four-degree cylinder surface coordinate palletizing robot, primarily moving through horizontal movement axis, vertical movement axis, rotation foundation, and hand axis. The multilayer palletizing capability enables fork movement into storage. This equipment utilizes PLC touch screen and intelligent management systems that are not only simple to operate but also reduce labor requirements.
Robotic Palletizing System Technical Parameters
Model No. AGMT-SR-210
Drive AC servo motor drive
Installation On floor
Max Palletizing Weight (contains weight of gripper) 210kgs
Handing Capacity 1700 Times/Hour
Movement Axis Normally 4 axes: A, B, C, D (can be 6 axis)
Movement scope - A-Axis (Horizontal) 1500mm
Movement scope - B-Axis (Vertical) 2300mm
Movement scope - C-Axis (Body) 330°
Movement scope - D-Axis (Gripper) 330°
Location Accuracy ±0.5mm
Power 6.5KVA
Compressed Air 0.5Mpa
Robot Weight (not contains weight of gripper) 1150kgs (+/-10%)
Software Unit
  • Chinese and English or other language supported operation
  • Main machine parts use famous brand motors like SEW
  • Built-in palletizing software package
  • Convenient pallet status confirmation
500-800 Packages/Hour Pick And Place Robot Palletizing System With Korean PLC And 4 Axis Movement
Key Features
  • Simple structure, low failure rate and convenient maintenance
  • Few main parts and accessories, low maintenance cost
  • Low power consumption - only 1/3 consumption of comparable mechanical stacker cranes
  • Minimal floor space requirements with high floor utilization ratio
  • Diverse gripper options to flexibly adapt to various palletizing requirements
Commissioning and After-sales Service
We provide accurate factory layout design according to customer's factory dimensions. If required, we can create comprehensive workshop designs including electrical power, water supply, gas power, material storage, final storage areas, and workers' restroom facilities. For commissioning services, we can dispatch 1-2 engineers to your factory for installation and adjustment of the processing line to achieve normal production in the shortest possible time.
Installation Instructions
We supply comprehensive user manuals and electrical drawings for all machines to facilitate self-installation. If self-installation is not feasible, we can send engineers to your factory for professional installation and debugging services.
