4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
Specifications
Brand Name :
AGMT
Model Number :
140H
Certification :
CE
Place of Origin :
Hefei, Anhui, China
MOQ :
One unit
Price :
26280
Payment Terms :
L/C,T/T
Supply Ability :
50 units/month
Delivery Time :
30-40 working days
Packaging Details :
Film wrapped and packed in wooden case
Application :
Beverage, Food, fertilizer etc.
Color :
Body yellow
Type :
Palletizer robot
Controller System :
PLC controller
Dimension(L*W*H) :
according to the workshop layout
Max. Payload :
50-180kg (with gripper)
Product capacity :
Multi lines, 8s per cycle
Control language :
English or customized
Description
4 Axis Work Envelope FANUC Palletizing Robot Used In Factory
4 Axis Work Envelope FANUC Palletizing Robot Robotic Arm Robots Used In Factory
STABLE PALLETIZING ROBOT
Designed specifically for palletizing applications, the Palletizer Series features five unique robots with payload capacity from 80 kg to 500 kg to suit most needs. With industry leading work range and reliability, FANUC stable palletizing robots help companies improve production line efficiency.
Robot Specifications
Item Specification
Type M-410iB/140H
Controlled axes Articulated type
Reach 2.85m
Installation Floor
Motion range (Mx=ax. Speed) J1 axis rotation: 360° (140°/sec) 6.28 rad (2.44 rad/sec)
J2 axis rotation: 155° (115°/sec) 2.71 rad (2.01 rad/sec)
J3 axis rotation: 112° (135°/sec) 1.95 rad (236 rad/sec)
J4 axis wrist swing: 20° (135°/sec) 0.35 rad (2.36 rad/sec)
J5 axis wrist rotation: 720° (420°/sec) 12.57 rad (7.33 rad/sec)
Max. load capacity at wrist Max. 140kg
Max. load capacity at J2 base 550kg
Max. load capacity at J3 arm 140kg
Allowable load inertia at wrist J4 axis: 147kg.㎡ 1500kgf.cm.sec²
J5 axis: 53 kg.㎡ 540kgf.cm.sec²
Drive method Electric servo drive by AC servo motor
Repeatability ±0.2mm
Mass 1200kg
Installation Environment Ambient temperature: 0-45℃ Ambient humidity: Normally 75% RH or less (no dew, nor frost allowed). Vibration: 0.5G or less
Acoustic noise level 74dB
Installation Instructions
We will supply you the user manual and electrical drawing of all the machines for you to install the machines by yourself. If you think you cannot install the machines by yourself, we can send engineer to your factory for installing and debugging etc.
Package and Delivery
Machine film wrapped and packed in exported fumigation wooden box, then transported to departure port which customer required like Shanghai, Ningbo, Qingdao, Suzhou etc.
4 Axis FANUC Palletizing Robot with 140kg Payload and PLC Controller for Industrial Automation
Robot Features
  • Increased handling capacity to 1200 cycles/hour
  • The J1 axis has 360-degree rotation space for multi-directional operation
  • Large wrist load, load 140 kg
  • Wide range of motions up to a radius of 2850 mm
  • 4-axis construction for high speed palletizing and handling
  • Two optional stands: bench and compact
  • The controller is integrated in the base for easy installation and transportation
  • Smart function iRVision, ROBOGUIDE
Why Choose Us
  • We will help you with the program of Kawasaki, and the basement and grab hands. So that you can easily use it.
  • Also, we will send our technician to your factory workshop to train your operator until they know how to use.
  • We have done many projects of ABB robot palletizing together with our packing and filling system to be a whole system. We have many brands of robot, not only ABB, but also Kawasaki, Fanuc, Kuka etc. and we can select the best suitable & cheapest robot model for you.
Frequently Asked Questions
Q: Do you offer Installation & debugging?
A: Our engineers are available to service machinery overseas to help customers to solve machine problems.
Q: What's policy for guarantee and broken parts?
A: As for machine products, our company provides 12 months for all mechanical parts with the exception of electrical and electronic parts and those subjects to normal wear and tear. Meanwhile, the guarantee starts from the shipment (B/L date). The guarantee is intended limited to the replacement of the broken part after checking the construction fault. The inspection of the causes of the trouble or the breakdown of the parts is exclusively up to the manufacturing company. All in all, our company can offer you assured products.
Q: How do we test your machinery?
A: When the machine completely manufactured, we will send video for check, and you also can come to our factory to test and learn how to operate it.
