RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm
Specifications
Brand Name :
RUYA
Model Number :
RA515
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 pc
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
1-10 pieces，2 weeks
Delivery Time :
5-10 working days
Packaging Details :
Flight case + Wooden box
Accuracy :
0.035mm
Repeatability :
0.025mm
Description

RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm


Product Description


RUYA RA515 Articulated Arm Coordinate Measuring Machine Portable CMM High Precision 3D Measuring Arm

Instrument composition
1—fixed platform,
2—Magnetic stand (or suction cup, tripod),
3—Measuring machine host,
4—computer and software,
5—The measuring head consists of several parts.
When measuring, it must be stably fixed on the platform (it is not required to be level but the relative position of the measuring machine and the workpiece to be measured is required to be stable during the whole measuring process), the main unit of the measuring machine is fixed by a suction cup or screws, the portable computer is connected to the main unit through a USB signal line, and the software is completed Acquisition and processing of measurement data and production of measurement reports.


Geometric feature detection

1. Measure the geometric features on the workpiece. And through projection and intersection, existing geometric features are fitted to generate new features.

2. Quickly analyze spatial dimensions such as distances and angles between geometric features.

3. The coordinate system can be customized through points, lines, and surfaces, and linear dimensions can be marked.

GD&T geometric tolerance detection

The measurement software provides GD&T tools to evaluate the form and position tolerances of geometric features. For example, verticality, parallelism, flatness, cylindricity, coaxiality, inclination, position, etc.

Comparison between 3D model and actual object

The software is compatible with multiple 3D data formats and provides multiple coordinate alignment methods. It can automatically compare measured geometric features and surface point data with theoretical values on the three-dimensional model, and provide error analysis graphic reports.

Test report

Test reports in PDF, Excel, and mht formats can be quickly output.

The inspection report customization function is powerful, and the output report is convenient and fast, with pictures and texts.


Application fields: used in automobile production line, aerospace, shipbuilding, inspection fixture manufacturing, mold manufacturing, etc.


Product parameters


RA5 Series Specification
Model Spatial measurement range/m Space-length indication error/mm Uniaxial coordinate measurement consistency /mm
RA515 1.5m 0.035mm 0.025mm
RA520 2.0m 0.045mm 0.032mm
RA525 2.5m 0.060mm 0.035mm
RA530 3.0m 0.080mm 0.056mm
RA535 3.5m 0.100mm 0.071mm



Optional Accessories:
