Specifications
Model Number :
ZL-1042B
Total Counter :
0 to 99999999 (preset)
MOQ :
1 set
Delivery Time :
7-14 work days
Test Stations :
2 sets
Brand Name :
ZL
Test Rate :
Adjustable from 5 to 60 cycles/min (LED display)
Packaging Details :
wooden case packaging
Payment Terms :
D/A,L/C,D/P,T/T
Sample length :
1 meter
Certification :
CE,ISO
Bending Angle :
5° to 180° (±90°)
Price :
UDS2600-4000
Weights :
2 each of 100/200/300/500/1000g (customizable)
Supply Ability :
30 Sets
Name :
Wire Flexing Fatigue Tester
Place of Origin :
Guangdong, China
Test Wire Diameter :
1 to 20mm (customizable)
Description
Cable Bending Testing Machine IEC60227 IEC60245 Wire Flexing Fatigue Tester for Power Cord Repeated Bending Resistance Test
Product Overview

The cable bending tester is designed for manufacturers and quality inspection departments to perform bending (flexing) tests on cables. The test method involves securing the cable to a clamp, which then swings left and right a predetermined number of times until electrical continuity is lost. The machine automatically stops operation at this point, and the total number of swings is recorded for analysis.

Technical Specifications
Test Rate Adjustable from 5 to 60 cycles/min (LED display)
Total Counter 0 to 99,999,999 (preset)
Bending Angle 5° to 180° (±90°)
Test Wire Diameter 1 to 20mm (customizable)
Test Stations 2 sets
Weights 2 each of 100/200/300/500/1000g (customizable)
Sample Length 1 meter, 600mm attached to bending arm, weights placed 215mm below clamping device
Circuit Protection 24V circuit breaker detector
Bending Guide Wheel 50mm diameter (customizable)
Power Supply AC220V 50HZ ±10%
