Hengfu IBR 686 Roof Sheet Roll Forming Machine High Speed Trapezoidal Metal Roofing Machine
This IBR 686 roof sheet roll forming machine is engineered for high-efficiency production of trapezoidal metal roofing sheets, specifically designed for the African market. The machine features a robust 350H steel welded frame with 16 mm thick wall plate construction, ensuring exceptional stability and long-term durability during continuous operation. With 23 forming stations and 80 mm solid shafts manufactured from premium 45# steel, the machine delivers precise forming performance and consistent sheet quality.
The power and transmission system incorporates a 7.5 kW servo motor paired with a reliable chain transmission, achieving production speeds up to 40 meters per minute. The rollers, crafted from 45# steel with precision machining and surface hardening, significantly enhance wear resistance and extend operational lifespan.
A key feature is the cutting system, which utilizes a servo-driven flying cutting device with patented linear guide rail technology. This enables smooth, precise cutting without interrupting machine operation, resulting in optimal efficiency and minimal material waste. Cutting blades are manufactured from Cr12 alloy steel, providing superior hardness and durability.
The control system is PLC-based with an integrated touchscreen interface, offering intuitive operation and user-friendly functionality. The machine supports automatic length setting and precise counting capabilities, making it ideal for large-scale production requirements.
This model is particularly well-suited for African markets due to its robust construction, stable performance, and compatibility with galvanized steel and other commonly used roofing materials in the region. It represents an optimal solution for roofing sheet manufacturers seeking high productivity, minimal maintenance, and extended service life.
Technical Specifications
Model NO. 686 Roll Forming Machine
Usage Roof, Wall, Floor
Speed 0-40m/Min
Main Motor 7.5kw
Voltage 380V/50Hz, 3p or Customized as Customer' Request
Roller Station 23 rows
Spindle diameter 80mm (solid shaft)
Transmission method Gear transmission
Cutting method Linear guide shear
Touch screen PLC
Origin Botou cangzhou hebei
Warranty 1 year
Product Gallery
Hengfu IBR 686 Roof Sheet Roll Forming Machine with 40m/min Production Speed, 23 Forming Stations, and PLC Control System for High-Efficiency Trapezoidal Metal Roofing Hengfu IBR 686 Roof Sheet Roll Forming Machine with 40m/min Production Speed, 23 Forming Stations, and PLC Control System for High-Efficiency Trapezoidal Metal Roofing Hengfu IBR 686 Roof Sheet Roll Forming Machine with 40m/min Production Speed, 23 Forming Stations, and PLC Control System for High-Efficiency Trapezoidal Metal Roofing Hengfu IBR 686 Roof Sheet Roll Forming Machine with 40m/min Production Speed, 23 Forming Stations, and PLC Control System for High-Efficiency Trapezoidal Metal Roofing
Frequently Asked Questions
Can a single machine produce multiple types of profiles?
Standard models are typically designed to produce one specific profile type per machine. However, customizable models—such as those with interchangeable rollers, double-layer machines, or triple-layer machines—can be configured to enable a single machine to serve multiple purposes.
Does the machine require a foundation?
It simply requires a level concrete floor; no complex foundation is necessary.
Does the machine require disassembly for transport?
The core structure remains intact; only the auxiliary components are removed to ensure that precision is maintained.
There are no professional maintenance personnel available locally; what should we do in the long run?
We provide lifetime remote video guidance; most issues do not require on-site repair.
Are customers able to visit the factory to test the machine and observe its performance firsthand?
We welcome customers—or a designated third party—to visit our factory to inspect the machine and conduct trial production runs using their own materials.
