10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
10 Tons Automated Material Handling Systems RGV Rail Transfer Cart
Specifications
Brand Name :
RMK
Model Number :
KPX
Certification :
CE.ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
customized
Payment Terms :
T/T
Supply Ability :
300 set per year
Delivery Time :
60 days
Packaging Details :
tarp
Name :
10T Automated Material Handling Systems RGV rail transfer trolley
load capacity :
10T
Wheel material :
steel
Brake :
Electric motor brakes
Max Capacity :
200ton
Application :
Warehouse, Factory, Hospital
Material :
Steel
Usage :
Transportation
Warranty :
1 Year
Description

10 Tons Automated Material Handling Systems RGV Rail Transfer Cart

10 tons automated track RGV, powered by low-voltage track mode, with two operating modes: central control system and wireless remote control. The overall structure of the RGV series rail electric flat cart is mainly composed of a frame, transmission device, walking device (wheel), conductive device, safety device, onboard control box, etc.

10 Tons Automated Material Handling Systems RGV Rail Transfer Cart

10 Tons Automated Material Handling Systems RGV Rail Transfer Cart

Technical parameters for Battery powered electric transfer carts KPX series
Model KPX-2t KPX-5t KPX-10t KPX-20t KPX-25t KPX-30t KPX-40t KPX-50t KPX-150t
Rated Load(t) 2 5 10 20 25 30 40 50 150
Table Size(mm) Length 2000 3500 3600 4000 4500 4500 5000 5500 10000
Width 1500 2000 2000 2200 2200 2200 2500 2500 3000
Height 450 500 500 550 600 600 650 650 1200
Wheel Base(mm) 1200 2500 2600 2800 3200 3200 3800 4200 7000
Rail Inner Gauge(mm) 1200 1435 1435 1435 1435 1435 1435 1435 2000
Wheel Diameter(mm) Ø270 Ø300 Ø300 Ø350 Ø400 Ø400 Ø500 Ø500 Ø600
Wheel Quantity 4 4 4 4 4 4 4 4 8
Ground Clearance(mm) 50 50 50 50 50 50 50 50 75
Running Speed(m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 1 1.2 1.6 2.2 3 3.5 4 5 15
Battery Capacity (Ah) 180 180 180 180 250 250 300 330 600
Battery Voltage(V) 24 36 48 48 48 48 48 48 72
Running Time When Full Load 4.32 5.4 4.8 4 4 3.5 3.6 3.3 2.9
Running Distance for One Charge (Km) 6.5 8.1 7.2 4.8 4.8 4.2 4.3 4 3.2
Max Wheel Load (KN) 14.4 25.8 42.6 77.7 94.5 110.4 142.8 174 266
Reference Weight(t) 2.8 3.6 4.2 5.9 6.5 6.8 7.6 8 27
