10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
10p10c Smt Rj50 Connector 10 Position Surface Mounting Ethernet Socket
Specifications
Brand Name :
LINK-PP
Model Number :
LPJE1606DNL
Certification :
ISO9001,SGS,UL,CE,REACH,RoHS
Place of Origin :
GuangDong, China
MOQ :
1000
Price :
Supportive
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3000000/Month
Delivery Time :
Stock
Packaging Details :
Reel&Carton
Specifications :
RJ50 SMD 10p10c
PN. :
LPJE1606DNL
Mounting :
SMD
Application :
Cat3,5
Termination :
Solder
LEDs :
None
Description
10p10C SMT RJ45 Connector 10Position Surface Mounting Ethernet Socket Shield

Key :

10pin SMD Rj45 / 10Pin Rj45 Surface Mounting Side Entry / 1.27mm SMD pin layout / 10P10C SMT Rj45

10Position PCB Connector.

NOTES
MATERIAL
1.HOUSING MATERIAL : HIGH TEMP THERMOPLASTIC
FLAMMABILITY RATING UL94V-0.
2.CONTACT MATERIAL : PHOSPHOR BRONZE T=0.3mm.
3.PLATING : GOLD LATING OVER NICKEL IN CONTACT
TIN PLATING OVER NICKEL IN SOLDER AREA.
FU",3U",6U",15U",30U",50U".
4.SHIELD : 0.20mm THICKNESS COPPER ALLOY
WITH NICKEL PLATED.
ELECTRICAL
1.VOLTAGE RATING : 125 VAC RMS.
2.CURRENT RATING : 1.5 AMP.
3.CONTACT RESISTANCE : 30 MILLIOHMS MAX.
4.INSULATION RESISTANCE : 500 MEGOHMS MIN @ 500V DC .
5.DIELECTRIC RESISTANCE : 1000V AC RMS 50Hz. 1MIN.
MECHANICAL
1.DURRABILITY : 750 CYCLES MIN.
2.PCB RETENTIONPRE-SOLDER : 1 LB MIN.
ENVIRONMENTAL:
RoHS
2011/65/EU
3.UL Certification : File Number E484635
