10/100Mbps SMT LED RJ45 Connector LPJ3026ABNL
10/100Mbps SMT LED RJ45 Connector LPJ3026ABNL
Specifications
Place of Origin :
China
Brand Name :
LINK-PP
Certification :
SGS, UL,CE,ISO9001,Reach,RoHS
Model Number :
LPJ3026ABNL
MOQ :
770
Price :
Supportive
Packaging Details :
110PCS/Reel,7Reels=770PCS=10KG=35.5*35.5*35cm/Carton
Delivery Time :
Stock
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
3000K/month
Specification :
LPJ3026ABNL
Gender :
Female
Indicators :
LEDs
Mounting :
SMD
Speed :
10/100Mbps
Samples :
Available
Description

10/100Mbps SMT LED RJ45 Connector LPJ3026ABNL

  1. 1X1 Port Tab-up rj45 jack With LED Indicator
  2. Surface Mount SMT RJ45 Connector
  3. SMD Jack Rj-45 Four 10/100BASE-TX Fast Ethernet ports


Electrical Specifications @25℃
1.Turns Ratio(±2%):
TX=1CT∶1 RX=1CT∶1CT
2.OCL:
350uH Min with 8mA bias current
3.Return Loss(dB Min @100Ω±15Ω):
1-10MHz:-20 30MHz:-16
60-80MHz:-12
4.Crosstalk(dB Min):
1-10MHz:-40 30-60MHz:-35
60-100MHz:-30
5.Insertion Loss:
1-65MHz:-1.0dB Max
6.Common Mode Rejection(dB Min):
1-50MHz:-30 50-130MHz:-20
7.Isolation Voltage: 1500Vrms Min
8.Operating Temperature: 0℃～70℃

10/100Mbps SMT LED RJ45 Connector LPJ3026ABNL
