ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
Specifications
Brand Name :
ADVANTEST
Model Number :
R3755A
Certification :
CE
Place of Origin :
Japan
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
in stock
Delivery Time :
2 WEEKS
Packaging Details :
Carton
Product name :
Network Analyzer
Ripple & Noise :
Ripple & Noise 20 Hz to 20 MHz
Normal Mode Voltage: :
<8 mVpp / 1 mVrms
Normal Mode Current: :
<4 mArms
Condition :
Pre-Owned
Functions :
Tested, in Full Working Conditions
Description
ADVANTEST 300 MHz Board Network Analyzer R3755A With High Precision
Product Overview
The R3755A network analyzer evaluates the frequency characteristics of electronic components, such as crystal resonators and ceramic resonators used in a broad range of electronic equipment, as well as antennas for receiving/transmitting wireless signals.
Measurement Functions
Measurement channels4
Measurement parametersA/R (R channel is connected internally)
Signal Source Characteristics
Frequency range10 kHz to 300 MHz
Resolution1 mHz
Accuracy+20 ppm (OPT.20: +1 ppm)
Output range10 kHz to 1 MHz: 0 to -30 dBm
1 to 300 MHz: +18 to -43 dBm
Resolution0.1 dB
Range set-upStart/Stop, or Center/Span
Sweep typeArbitrary sweep of specified segment
Sweep speedMaximum 50 usec/point (RBW 15 kHz)
Measurement pointMaximum 1601 points (segment)
Output portSMA (female) 50Ω connector
Receiving Section Characteristics
Input characteristicsSMA (female) 50Ω connector
General Specifications
Loadable PC expansion slots2
Development environmentWindows XP sp2 MS VB Net Framework 2.0 or more
Microsoft Visual Basic 6.0 or Visual C++ 6.0
Power supply+5 VDC (7W), +3.3 VDC (10W), +12 VDC (1W), -12 VDC (1W) (typical)
Power consumption20 W or less
External dimensionsApprox. 190 (W) x 126 (H) x 42 (D) mm
Mass1 kg or less
Product Specifications
Model NoR3755A
ConditionUsed
ManufacturerAdvantest
Optional Feature
This option can change the maximum follow-up voltage in the 1 mA and 10 mA ranges to 1200 V.
Product Images
ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels ADVANTEST R3755A 300 MHz High Precision Network Analyzer with 4 Measurement Channels
Frequently Asked Questions
Can you ship order to Canada or Australia?
Yes, we can. We send orders worldwide.
What delivery method do you use? and delivery time?
We can ship by EMS, DHL, FedEx, UPS, TNT with tracking number. Usual delivery time is 4-7 workdays.
What is your payment term?
100% T/T payment before shipment.
How can I ask any other question?
You can contact us online or leave us messages below.
