SFP-2860 / SFD-2860 UF Membrane Module with 51 M² Membrane Area, PVDF Material, and 0.03 µm Nominal Pore Diameter
SFP-2860 / SFD-2860 UF Membrane Module with 51 M² Membrane Area, PVDF Material, and 0.03 µm Nominal Pore Diameter
SFP-2860 / SFD-2860 UF Membrane Module with 51 M² Membrane Area, PVDF Material, and 0.03 µm Nominal Pore Diameter
SFP-2860 / SFD-2860 UF Membrane Module with 51 M² Membrane Area, PVDF Material, and 0.03 µm Nominal Pore Diameter
SFP-2860 / SFD-2860 UF Membrane Module with 51 M² Membrane Area, PVDF Material, and 0.03 µm Nominal Pore Diameter
SFP-2860 / SFD-2860 UF Membrane Module with 51 M² Membrane Area, PVDF Material, and 0.03 µm Nominal Pore Diameter
Specifications
MOQ :
1 Set
Delivery Time :
7 work days
Flow Range Diameter :
8 Inch
Component Filtration Accuracy :
0.01-0.1μm
Certification :
ISO 14001， CE ，ISO 9001
Nominal Pore Diameter :
0.03 µm
Model Number :
SFP-2860 / SFD-2860
Component Flow Range Membrane Area :
51 M²
Component Flow Range :
2.0 – 6.1 M3 /hr
Payment Terms :
T/T,Western Union,Paypal etc.
Component NaOCl (Max.) :
2,000 Mg/L
Price :
Negotiable
Flow Direction Settings :
External Pressure Structure, Dead End Filtration
Supply Ability :
200 Units per Month
Max Backwash Pressure :
2.5 Bar
Place of Origin :
China
Material :
PVDF
Packaging Details :
Standard Export Wood Crate/Carton or Naked wrapped by film
Description
SFP-2860 / SFD-2860 High-Performance UF Membrane Module – Industrial Ultrafiltration Solution
Advanced Ultrafiltration Solution for Industrial Water Treatment

The SFP-2860 / SFD-2860 Ultrafiltration Membrane Module is a high-efficiency membrane filtration solution designed for industrial water purification and advanced pretreatment applications.

Utilizing advanced hollow fiber ultrafiltration technology, the module provides precise removal of suspended solids, colloidal particles, microorganisms, and other contaminants while maintaining stable filtration performance and high water recovery.

With excellent filtration accuracy, reliable mechanical strength, and long-term operational stability, the module is suitable for a wide range of applications including industrial process water treatment, wastewater reuse, and reverse osmosis pretreatment.

The compact module design allows flexible system integration, easy maintenance, and efficient operation in both new installations and water treatment upgrades.

Key Advantages
High Precision Filtration Performance
  • Effectively removes suspended solids, colloids, bacteria, and microorganisms
  • Produces high-quality filtrate for downstream treatment processes
  • Improves protection of RO and other purification systems
Advanced UF Membrane Technology
  • Hollow fiber membrane structure
  • High filtration efficiency
  • Stable permeability during long-term operation
  • Excellent resistance to common operating conditions
Reliable Industrial Operation
  • Designed for continuous-duty applications
  • Strong mechanical durability
  • Suitable for demanding water treatment environments
Flexible System Integration
  • Compatible with various UF system configurations
  • Suitable for skid-mounted and containerized treatment systems
  • Easy replacement and maintenance
Product Specifications
Parameter Specification
Product Model SFP-2860 / SFD-2860
Technology Ultrafiltration (UF)
Membrane Type Hollow Fiber Membrane
Filtration Mode Cross-flow / Dead-end Operation (System Dependent)
Application Industrial Water Treatment
Filtration Accuracy High Precision Ultrafiltration
Membrane Function Suspended Solids & Microorganism Removal
Installation Type Modular UF System Integration
Typical Applications

The SFP-2860 / SFD-2860 UF Membrane Modules are widely applied in:

  • Industrial raw water purification
  • Reverse osmosis pretreatment
  • Municipal water treatment
  • Industrial wastewater reuse
  • Process water filtration
  • Food and beverage water treatment
  • Electronics manufacturing water systems
  • Power plant water treatment
Product Benefits
Feature Benefit
High Filtration Accuracy Produces cleaner feed water
Compact Module Design Saves installation space
Stable Performance Supports continuous operation
Low Maintenance Reduces operating requirements
High Reliability Suitable for industrial applications
UF Pretreatment Capability Protects downstream RO systems
Reliable Filtration for Industrial Water Applications

The SFP-2860 / SFD-2860 provides an efficient ultrafiltration solution for industries requiring accurate particle removal, stable water quality, and reliable long-term operation. Its advanced membrane structure makes it an ideal choice for modern water purification and reuse systems.
