1m ohm（0.001 ohm） 0612 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
1m ohm（0.001 ohm） 0612 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
1m ohm（0.001 ohm） 0612 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
1m ohm（0.001 ohm） 0612 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
1m ohm（0.001 ohm） 0612 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
1m ohm（0.001 ohm） 0612 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
Specifications
Model Number :
HTE1206M1W5R001F
Tolerance :
±1%
MOQ :
5000
Packaging Details :
5000
Brand Name :
Walter
Temperature Coefficient :
±100 ppm/°C
Place of Origin :
Made in China
Certification :
RoHS / REACH
Supply Ability :
Large volume available
Payment Terms :
T/T
Power Rating :
1W
Operating Temperature :
-55°C to +155°C
Price :
Negotiable
Delivery Time :
3-5 work days
Material :
MnCu alloy
Resistance Range :
1m ohm（0.001 ohm）
Description

0612 Wide Terminal Resistor 1m Ohm Metal Foil Resistor 1.5W. This 0612 wide terminal chip resistor from Walter HTE series delivers 1m ohm(0.001 ohm) resistance with ±1% tolerance and 1W rated power, giving designers a compact surface-mount part that keeps performance steady under load and temperature.

Technical Specifications
ParameterSpecification
NameWide Terminal Resistor
ManufacturerWalter
SeriesHTE
Size0612
Resistance Range1m ohm(0.001 ohm)
Tolerance±1%
Power Rating1W
Operating Temperature Range-55°C to +155°C
Temperature Coefficient±100 ppm/°C
Key Features
  • Stable 1W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±100 ppm/°C temperature coefficient that keeps values stable as the board heats up
  • MnCu alloy element material for consistent, repeatable performance
  • Compact 0612 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications

This wide terminal chip resistor suits Current Sensing, Power Supplies, Motor Control, Battery Management. Its MnCu alloy construction and stable electrical behaviour help designers meet tight tolerances in current sensing, power conversion and protection circuits, while the 0612 body keeps the layout compact.

Why Choose This Part

Buying directly from the manufacturer keeps the HTE series series available at competitive pricing with short lead times. Every batch is electrically tested before packing, so the resistance and tolerance you specify are the values you receive.

Packaging & Quality Assurance

Supplied on tape and reel for automatic pick-and-place assembly, in standard reel quantities for SMT lines. Every shipment is RoHS and REACH compliant and can be accompanied by a certificate of compliance on request. Contact us for samples, datasheets and volume pricing tailored to your project.

1m ohm（0.001 ohm） 0612 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD Application reference: 0612 Wide Terminal Resistor 1m Ohm Metal Foil Resistor 1.5W
