3m ohm（0.003 ohm） 0508 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
3m ohm（0.003 ohm） 0508 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
3m ohm（0.003 ohm） 0508 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
3m ohm（0.003 ohm） 0508 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
3m ohm（0.003 ohm） 0508 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
3m ohm（0.003 ohm） 0508 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
Specifications
Power Rating :
1W
Supply Ability :
Large volume available
Delivery Time :
3-5 work days
Material :
MnCu alloy
Brand Name :
Walter
Place of Origin :
Made in China
Size :
0508(1.2mm*2.0mm)
MOQ :
5000
Tolerance :
±1%
Temperature Coefficient :
±100 ppm/°C
Price :
Negotiable
Payment Terms :
T/T
Series :
HTE
Applications :
Current sensing, power supply, motor control, battery management, frequency converter, 5G base station, LED lighting,
Certification :
RoHS / REACH
Operating Temperature Range :
-55°C to +155°C
Features :
High precision, high power, low temperature ticket, low inductance
Manufacturer :
Walter
Resistance Range :
3m ohm（0.003 ohm）
Per Reel :
5000
Model Number :
HTE0805M1W0R003F
Packaging Details :
5000
Description
3m Ohm (0.003 Ohm) 0508 Wide Terminal Chip Resistor
High Power Wide Terminal Resistor 1W 3m Ohm Resistor 0508 Size For Power Applications. This 0508 wide terminal chip resistor from Walter HTE series delivers 3m ohm (0.003 ohm) resistance with ±1% tolerance and 1W rated power, giving designers a compact surface-mount part that maintains consistent performance under load and temperature variations.
Technical Specifications
ManufacturerWalter
SeriesHTE
Size0508 (1.2mm × 2.0mm)
Resistance Range3m ohm (0.003 ohm)
Tolerance±1%
Power Rating1W
Operating Temperature Range-55°C to +155°C
Temperature Coefficient±100 ppm/°C
MaterialMnCu alloy
Key Features
  • Stable 1W rated power handling for demanding circuits
  • ±1% tolerance for dependable measurement accuracy
  • Low ±100 ppm/°C temperature coefficient that maintains stable values during temperature fluctuations
  • MnCu alloy element material for consistent, repeatable performance
  • Compact 0508 SMD footprint suitable for high-density reflow assembly
  • RoHS / REACH compliant construction for lead-free manufacturing
Applications
This wide terminal chip resistor is ideal for current sensing, power supply systems, motor control, battery management, frequency converters, 5G base stations, and LED lighting applications. The MnCu alloy construction and stable electrical characteristics help designers achieve tight tolerances in current sensing, power conversion, and protection circuits, while the compact 0508 body enables space-efficient layouts.
Quality & Manufacturing Advantages
Sourced directly from the manufacturer, the HTE series offers competitive pricing with short lead times. Every batch undergoes comprehensive electrical testing before packaging, ensuring the specified resistance and tolerance values are consistently delivered.
Packaging & Compliance
Supplied on tape and reel for automated pick-and-place assembly in standard reel quantities suitable for SMT production lines. All shipments comply with RoHS and REACH standards, with certificates of compliance available upon request. Contact us for samples, datasheets, and volume pricing tailored to your project requirements.
3m ohm（0.003 ohm） 0508 Wide Terminal Chip Resistor 1W ±1% HTE Walter High Precision SMD
Application reference: High Power Wide Terminal Resistor 1W 3m Ohm Resistor 0508 Size
