Specifications
Model NO. :
ES3J
Structure :
GPP Junction
Material :
Silicon
Transport Package :
Tape Reel
Specification :
Surface Mount Package
Trademark :
JF
Origin :
China
HS Code :
85411000
Supply Ability :
10000000000piece/Year
Place of Origin :
China
Certification :
ISO9001:2015, ISO14001:2015, IATF16949
MOQ :
3,000 Pieces
Price :
Negotiable
Delivery Time :
Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays
Payment Terms :
LC, T/T, PayPal
Description
Product Description

GLASS PASSIVATED JUNCTION SUPER FAST RECTIFIER DIODE
Electronics Component

Part Number: ES3A THRU ES3K

Major Parameter:

Type VRRM IF IR(25ºC) IR(100ºC) IR(125ºC) VF Trr Outline
V A μA uA uA V nS
ES3A 50 3.0 5.0 100 0.95 35 SMB
( DO-214AA )
ES3G 400 3.0 5.0 100 1.25 35
ES3J 600 3.0 5.0 100 1.7 35
ES3K 800 3.0 5.0 100 2.2 35

Brand: JF

Package: SMB /DO-214AA Plastic
Manufacturer: Jinan Jingheng Electronics Co., Ltd.

Features:

Plastic package has Underwriters Laboratory Flammability Classification 94V-0
Glass passived junction
Low power loss, high efficiency
High surge current capability
High speed switching, Low leakage
Low forward voltage drop
High current capability, High reliability
High temperature soldering guaranteed:260 C/10 seconds at terminals
Component in accordance to RoHS 2011 65 EU

Application:
Used in power supply, lighting, auto, home appliance field
