Specifications
Model NO. :
MURF2060CT
Luminous Intensity :
None Luminance
Color :
None Luminance
Structure :
Planar
Material :
Silicon
VRRM :
200V-600V
IF :
20A
PACKAGE :
ITO-220AB
USAGE :
ADAPTOR, POWER SUPPLY
Transport Package :
Tube
Specification :
High Power Package
Trademark :
JF, JH
Origin :
China
HS Code :
85411000
Supply Ability :
10000000000piece/Year
Package Size :
20.00cm * 40.00cm * 15.00cm
Package Gross Weight :
8.000kg
Place of Origin :
China
Certification :
ISO9001:2015, ISO14001:2015, IATF16949
MOQ :
3,000 Pieces
Price :
Negotiable
Delivery Time :
Peak Season Lead Time: one month Off Season Lead Time: within 15 workdays
Payment Terms :
LC, T/T, PayPal
Description
Product Description

SUPER FAST RECTIFIER DIODES
Electronics Component

Part Number: MURF2020CT/MURF2030CT/MURF2040CT/MURF2060CT

Major Parameter:

Type VRRM IF IR(25ºC) IR(100ºC) IR(125ºC) VF Trr Outline
V A μA uA uA V nS
MURF2020CT 200 2×10 5.0 50 0.975 35 ITO-220AB
MURF2030CT 300 2×10 5.0 50 1.3 35
MURF2040CT 400 2×10 5.0 50 1.3 35
MURF2060CT 600 2×10 5.0 50 1.7 35

Brand: JF / JH

Package: ITO-220AB package
Manufacturer: Jinan Jingheng Electronics Co., Ltd.

Features:

Plastic package has Underwriters Laboratory Flammability Classification 94V-0
Single rectifier construction
High surge capability
For use in low voltage ,high frequency inverters, free wheeling ,and polarity protection applications
High temperature soldering guaranteed:2 0 C/10 seconds, 0.25"(6.35mm)from case
Fast switching for high efficiency
Low forward voltage drop
Component in accordance to RoHS 2011 65 EU

Application:
Used in power supply, lighting, auto, home appliance field
