Energy Storage System Customized Solar Panels 400W Monocrystalline Bifacial PERC 108 Cells
Energy Storage System Customized Solar Panels 400W Monocrystalline Bifacial PERC 108 Cells
Energy Storage System Customized Solar Panels 400W Monocrystalline Bifacial PERC 108 Cells
Energy Storage System Customized Solar Panels 400W Monocrystalline Bifacial PERC 108 Cells
Specifications
Brand Name :
Silk
Model Number :
SFD-PV400M2-HP108F
Certification :
CE，IEC,CQC,CNAS
Place of Origin :
China
MOQ :
50pcs
Price :
Negotiable Price
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5MW PER MONTH
Delivery Time :
10-30 Days
Packaging Details :
CARTON WITH WOODEN PALLET
Product Name :
400 Bifacial Solar Panels
Material :
Solar cells+ Duable Glass
Max. Power :
400W
Panel Dimensions :
1722×1134×30mm
Open-Circuit Voltage(Voc) :
37.94V
Junction Box :
IP68 Rated
Description

Residential Energy Storage System Solar Panels 400W Monocrystalline Bifacial PERC 108Cells

400W Bifacial Glass Solar Panels Description:

1. The appearance of components are elegant and simple, perfectly combined with the architectural style.

2. 10BB is combined with 182*91mm cell technology, which has more reliable performance, effectively reduces the power loss caused and achieves higher power output.

3. Double-sided absorption of solar radiation, the double-sided ratio is as high as 70%, which greatly improves the equivalent power of the module

Solar Panel Application:

Highly used in Gound power plants, Commercial / Industrial roof-tops, Residential roof-tops, Agricultral PV Project

400W Bifacial Glass PanelsPamameters:

ELECTRICAL SPECIFICATION (STC)
Max-power 400
Power Tolerance 0~+6W
Voltage at Pmax (Vmp) 30.8
Current at Pmax (Imp) 12.99
Open-Circuit Voltage(Voc) 37.94
Short-Circuit Current (lsc) 13.8
Module Efficiency(%) 20.48
No. of Bypass Diodes(pcs.) 3
Max. Series Fuse(A) 25A
Operating Temperature - 45~+85 ℃
Max Static Load 5400P
Max-System Voltage(VDC) 1500 VDC(IEC)
Fire Rating Class C
STC: Irradiancec 1000W/m2, Cell Temperature 25 ℃,Air Mass 1.5

FAQ:

Q: Are you a manufacturer of trader?

A: We are a manufacturer of solar system kits, such as energy storage battery, solar inverters and solar panels.

Q: Can i use an AGM type battery for these 440W Solar Panels?

A: Yes. You can set the battery type to AGM according to the instructions. The battery types compatible with are as follows
SLA(lead-acid battery), GEL Battery, AGM Battery, Lithium-ion Battery, Ternary Lithium Battery

Q: How do you assure good quality products?

A: Quality is priority,100% 24 hours aging quality test before packing to assure reliable quality.
