Standard Type Plastic Crusher Manual Feed Grinder For Hard Plastics
Standard Type Plastic Crusher Manual Feed Grinder For Hard Plastics
Standard Type Plastic Crusher Manual Feed Grinder For Hard Plastics
Standard Type Plastic Crusher Manual Feed Grinder For Hard Plastics
Standard Type Plastic Crusher Manual Feed Grinder For Hard Plastics
Standard Type Plastic Crusher Manual Feed Grinder For Hard Plastics
Specifications
Brand Name :
RAYFON
Model Number :
RFSA
Place of Origin :
China
MOQ :
1
Delivery Time :
30-45days
Packaging Details :
Containers
Warranty Period :
1 year
Motor Power :
45-60kW
Fixed Blade :
4pcs
Rotating Blade: :
6pcs, 12pcs
Material :
Carbon Steel/SUS 304
Plastic Type :
PP/PE, PET, hard plastics, HDPE
Function :
crush plastics into small pieces
Screen Aperture :
18-22mm(adjustable)
Blade Holder Structure :
V Shaped
Pressure Method :
Flip Plate Pressing
Inside Plate Thickness :
500mm
Description

Standard Type Plastic Crusher Manual Feed Crusher for Hard Plastics

Standard Type Plastic Crusher Manual Feed Grinder For Hard PlasticsFunction:
The Manual Feed Plastic Granulator (Non-Pressure Feed System) is engineered for flexible processing of various plastic materials through open-hopper feeding. Designed for operations requiring frequent material changes or handling of oversized/bulky scrap, this machine efficiently reduces plastic waste into uniform granules without the complexity of automatic feeding mechanisms.

Key Features:

1.Large Open Hopper with Safety Grid:Features an oversized rectangular hopper (600×800mm standard) with 45° feed angle for ergonomic loading. Integrated removable safety grid prevents oversized materials and operator contact with cutting chamber.

2.Modular Maintenance Design:Split housing design with hydraulic opening system allows complete access to cutting chamber. Blade replacement can be performed without disassembling rotor bearings.

3.Intelligent Control System:PLC-based control panel with touchscreen interface displays real-time parameters: motor current, bearing temperature, operation hours. Features programmable start/stop sequences and fault diagnosis.

Standard Type Plastic Crusher Manual Feed Grinder For Hard Plastics

Equipment Specification:

ITEM UNIT RFSA-6060 RFSA-9060 RFSA-1270
Motor power kW/HP 30/41 45/62 75/102
Machine Length mm 1955 2085 2435
Machine Width mm 1425 1880 2140
Machine Height mm 2490 2575 2750
Chamber Size mm 600*600 900*600 1200*700
Rotating Blades pcs 6 9 12
Fixed Blades pcs 4 6 4
Rotor Diameter mm 540 540 665
Rotor Width mm 600 900 1200
Process Capacity KG/H ≤1000 ≤3000 ≤5000

Applications:

All kinds of plastic ,such as PET,PE,PP,HDPE plastics

PET plastic bottle

HDPE daily household waste containers

PP plastic busket, beverage cup

ABS PS Toy car
