Railway RTH62 Bottom-Discharge Open Top Wagon
Railway RTH62 Bottom-Discharge Open Top Wagon
Railway RTH62 Bottom-Discharge Open Top Wagon
Railway RTH62 Bottom-Discharge Open Top Wagon
Railway RTH62 Bottom-Discharge Open Top Wagon
Railway RTH62 Bottom-Discharge Open Top Wagon
Railway RTH62 Bottom-Discharge Open Top Wagon
Railway RTH62 Bottom-Discharge Open Top Wagon
Specifications
Brand Name :
Railteco
Model Number :
RTH62
Certification :
TSI EN UIC
Place of Origin :
China
MOQ :
One pcs
Price :
Negotiable
Payment Terms :
L/C,T/T
Supply Ability :
According to customer's requirement
Delivery Time :
6 months
Packaging Details :
Railteco Standard Packing
Name :
Railway Open Top Wagon
Axle Load :
25 T
Tare weight :
25.4t
Max. Operating speed(empty) :
120km/h
Volume Capacity :
88m³
Track Gauge :
1520mm (can be customized)
Standard :
EN,TSI,UIC
Payload :
70t
Length :
13980mm
Description

Railway RTH62 Bottom-Discharge Open Top Wagon


An open top wagon (or open wagon/gondola wagon) is a type of railway goods wagon characterized by its lack of a fixed roof. This fundamental design feature makes it ideally suited for loading and transporting materials that are best handled from above, either because of their nature, size, or weight. It is one of the most common and versatile workhorses of rail freight.

The open top wagon design is suitable for a vast range of materials, including:

  • Bulk Solids: Coal, ore, aggregates (sand, gravel), crushed stone.

  • Recyclables: Scrap metal, waste paper.

  • Industrial Products: Steel sections, rails, coils, pipes, large machinery.

  • Construction Materials: Logs, pre-cast concrete sections, ballast.

Railway RTH62 Bottom-Discharge Open Top Wagon

Parameters of Railway Flat Wagon:


Tare weight 25.4t
Gauge 1520mm (can be customized)
Load capacity 74t
Axle load 25t
Min curve radius 125m
Max. operating speed 120km/h
Length 13980mm


Description of Railway Open Top Wagon:

The wagon is designed for operation on 1520mm gauge railway, primarily for transporting construction machinery, mechanical equipment, coal, ore, and other goods that do not require protection against rain or snow.

The wagon mainly consists of a car body, bogies, air brake equipment, and coupler buffer device. The car body is primarily composed of an underframe, side wall, end wall, and bottom discharge door.

It is equipped with CA-3 automatic coupler compliant with relevant GOST standards, along with matching coupler yoke and MT-2 draft gear. The air brake system utilizes a GOST-compliant 6540 air control valve. The bogie is three-piece casting steel design.


Railway RTH62 Bottom-Discharge Open Top Wagon

Railway RTH62 Bottom-Discharge Open Top Wagon

Railway RTH62 Bottom-Discharge Open Top Wagon
