Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Specifications
Model Number :
LB-65//132
Guarantee :
12 Months
Price :
Negotiable（USD EUR）
Heating Method :
Light heating
Supply Ability :
15 SETS PER MONTH
Coolingmethod :
Air Cooling
Winding Pipe Diameter :
16-110mm
Brand Name :
LB
Extruder Model :
SJSZ65/132
Payment Terms :
L/C,T/T
Oven :
Two heating ovens
Plate :
single plate or double plate
MOQ :
1 SET
Delivery Time :
45 WORKING DAYS
Socket Type :
U or R socket
Plastic Processed :
PVC, UPVC
Packaging Details :
NORMAL PACKAGE
Type :
Full-automatic and Semi-automatic
Certification :
CE ISO
Belling Range :
16~630mm
Place of Origin :
ZHANGJIAGANG
Processing Type :
Pipe belling machine
Description
Automatic Pipe Belling Machine Temperature Control For Plastic Pipe Processing
Product Overview

The SGK Series Full Automatic Plastic Pipe Belling Machine features motor control bracket height adjustment for easy operation. This advanced system is configured with material-receiving pulling device and related process interfaces that integrate seamlessly with the main machine, enabling both collaborative and standalone operation.

  • Horizontal pipe movement ensures stable, accurate actions that prevent pipe damage
  • Infrared ray heating system with double-heating furnace configuration
  • Each heating furnace equipped with central heating furnace core
  • Expansion tube head shaping method for precise nozzle dimensions
  • Control panel includes conversion switches for expansion solvent plug (direct type) and expansion flexibility sealing washer type plug (R type)
  • Main electric control components utilize imported parts for stable, reliable system performance
Technical Specifications
Pipe Expand Range (Outer Diameter) Φ 20-630mm
Belling Type R type & U type
Used Oil Label No. 40/Hydraulic Oil
Quantity of Heater 2
Highest Temperature in Heater 280°C
Gas Pressure 0.6~0.8Mpa
Water Pressure 0.2~0.3Mpa
Pipe Length 3-6m
Center Height 900mm ± 50mm
Machine Dimensions 8615 × 3125 × 2500mm
Product Gallery
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Front View
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Side View
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Control Panel
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Heating System
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Pipe Processing Area
Automatic Pipe Belling Machine with 16~630mm Belling Range Infrared Heating System and Double Heating Oven for Plastic Pipe Processing
Overall Operation View
