Specifications
Place of Origin :
Beijing, China
Brand Name :
ALANDWELDING
condition :
New
type :
Multifunctional Tig Welders
arc current :
250A
pulse frequency :
50/60 HZ
pilot arc current :
41A
rated duty cycle :
60%
motor type :
AC DC MOTOR
dimensions :
560*240*460MM
usage :
Aluminum welding machine
voltage :
230V
power(w) :
/
weight (kg) :
30 KG
warranty :
1 Year
Power Supply Voltage :
1*230V 50/60Hz
Rate Input Capacity (KVA) :
10
Rate Input Current(A) :
41
No Load Voltage :
80
Output current Range :
TIG:3-200A;AC:5-200A;MMA:10-160A;CUT:20- 50A
Duty Cycle :
60%
Weight :
30kg
L*W*H(mm) :
560*240*460
Video outgoing-inspection :
Not Available
Machinery Test Report :
Not Available
Marketing Type :
New Product 2020
Warranty of core components :
1 Year
Core Components :
motor
Key Selling Points :
Multifunctional
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Home Use, Retail, Construction works , Other
Showroom Location :
None
Description
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
DESCRIPTION
Digital ControlIGBT inverter DC MMA,PulseACDC TIG and CUT. Lift and HF for TIG Hot arc start and arc force,Anti-stick for MMAHF or with HF pilot arc for Plasma cutting.32 bits MCU inside Foot pedal 2T/4T function Easy operation and normal selection for tig parameters. AC and DC mix pulse TIG Advanced square,soft square,triangular;sine, fourAC wave for selection.VRD for MMA (Option) PFC (option). 10memories for selection.
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
ALAND Numerical Control Multi Function Welding 3IN1 AC DC TIG MMA CUT Welding
MODEL
Digi-Multi 250 ACDC
INPUT
Voltage
1 xAC220V~240V 50Hz
DC
MMA
No-load Voltage
70V
Base current Adjusting Range
10~200A
Rated Output Current
200A
Rated Duty Cycle
60%
AC
TIG
No-load Voltage
70V
Current Adjusting Range
5~250A
SP % (AC balance)
10~70
AC Square Wave Frequency
30~250Hz
Rated Duty Cycle
60%
DC
TIG
Current Adjusting Range
5~250A
Rated Duty Cycle
60%
Standard
PULSE
TIG
Peak Current
5~250A
Base/peak Current ratio
5~95%
Rated Duty Cycle
60%
Pulse width
5%~95%
pulse Freq.
0.1~500Hz@DC
0.1~250Hz@AC ADV.SQUARE
0.1~10Hz@AC SOFT.SQUARE&TRIANGULAR&SINE WAVE
Advanced
PULSE
TIG
(MIX)
AC peak Current
5~200A
DC(base)/AC peak Current Ratio
5~95%
Rated Duty Cycle
60%
Pulse width
5%~95%
pulse (AC to DC-) Freq.
0.1~10Hz
Current UP/Down-slope Time
0~10S
Initial current/welding current
5~150%
crater-fill current/welding current
5~95%
Pre gas Flow Time
0~25s
Post gas Flow Time
0~25s
Arc starting Mode
HF/LIFT TIG
CUT
current Adjusting Range
15~60A
Rated Duty Cycle
60%
Post gas Flow Time
20~60s
Efficiency
≥80%
Mass
26kg
Protection Class of enclosure
IP21S
Outline Dimensions mm3
430x200x290
