55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A
55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A
55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A
55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A
55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A
55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A
Specifications
Brand Name :
procet
Model Number :
PT-PSE106GW-AR-D
Certification :
CE FCC
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
T/T, L/C
Supply Ability :
500PCS
Delivery Time :
Sample for 24 hours / Order within 20Days
Packaging Details :
120mm X 125mm X 44mm
Key Features :
single port fiber PoE Media converter with 4 Pair PoE
Model :
PT-PSE106GW-AR-D
Date speed :
Gigabit data rates
Operating Humidity :
20% to 80%,non-condensation
Output :
55V/1100mA
Input voltage :
36Vdc to 72Vdc 2.5mA
Weight :
280G
User Port Power :
60W Guaranteen
LED Indicator Power Indicator :
Green PoE Load Indicator: Green
Description

IEEE802.3at Power Injector DC input 36-72VDC 2.5A Output 55V 1100mA 60W

Key Specifications/Special Features:

1. PT-PSE106GW-AR-D is a single port midspan Injector with 4 Pair PoE up to 60 watts of power at 55 VDC at 1.1 amp.

2. Designed for the PoE++ powered 60W PoE Powered Devices (PDs), such as IP Cameras, wireless APs, Microwave radio, IoT application, door locks, displays, POS, and information kiosks, It supports 10/100/1000Mbps of data rates. Fully comply with IEEE802.3bt and remains compatible with any IEEE802.3af/at compliant devices. Equipped detecting chip inside, which will detect and classify PD before powering it, protecting non PoE device.

3. Enclosed in an IP40 fire retardant plastic case, designed for indoor installation with Wall-mounted. It operates with a wide input voltage of 36-72 VDC. The effective distance limitation of 100 meters over Cat5e/Cat6 cables can be extended with the PT-PEX-01G-OT(Outdoor or Indoor PoE Extender).

Model
PT-PSE106GW-AR-D
Pass Through Data Rates
Gigabit data rates
Power over Ethernet Output
Pin Assignment and Polarity1/2 (-), 3/6 (+)
Output Power Voltage:55VDC 1100mA
User Port Power:30W
AC Input Voltage: 36 to 72VAC 2.5A
AC Frequency:50 to 60 Hz
Protection
Over current protection
Over load protection
Over voltage protection
Anti-interference protection

55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A

55V 1100mA 60W IEEE802.3at Power Injector DC Input 36-72VDC 2.5A

FAQ

Q: Are you manufacturer or trading company?

A: Manufacturer, and industry network total solution provider.

Q: Do you accept ODM/OEM?

A: Yes. We provide customized service.

Q: What is your minimum order quantity?

A: MOQ is 1 unit.

Q: What’s the payment type?

A: T/T, L/C,Western Union, Money Cram, Credit Card, Alipay, Cash.

Q: What’s the accepted trade terms?

A: EXW, FOB, CIF, FAS, CIP, FCA, CPT, DED, etc.

Q: How about shipping time?

A: Within 3-15 days after receiving full payment , but if you need OEM/ODM, the lead time depends on the specific specifications of the product.

Q: How about after-sales service?

A: 7/24 hours online and respond to user's field device problems in time.

Q: How about the warranty?

A: 5 years.

More Infomations

Lead Time?

Order samples, we have in stock.

Bigger orders, 2-4 weeks after payment.

How to buy?

Click the BLUE BUTTON "Inquire now" (in the middle of page), input your order info and send to us.

Your sales consultant will contact you with 24 hr.

OEM/ODM Services?

YES. Tell us your demand, get the products you want.

For distributors, we can put your labels on it too.
