Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
CHINA
MOQ :
1
Price :
depend on product
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
Transit time: Est. 17-24 days
Mainbody Material :
16MnDR/Q235-B
Main Material :
Q345R
Function :
Low temperature storage
Key Words :
cryogenic liquid storage tank
Working Temperature :
-196 - 50 ℃
Storage Tank :
Vertical liquid co2 storage tank
Length :
6058mm
Filling Rate :
95%
Outer Vessel Material :
Carbon Steel
Filling Medium :
Liquid Nitrogen
Inner Vessel Material :
304 Stainless Steel
Description

10000L 20000L And 30000L Cryogenic Storage Tanks 8-bar 16-bar And 23-bar Tanks

Product Description


1.Cryogenic storage tank series adopts integrated design and leaves the factory after overall commissioning: the tank, pipeline, base, vaporization and pressurization are fully integrated, no installation and commissioning on site, zero distance from gas equipment, and low loss.

2.High vacuum multi-layer adiabatic winding, ultra-low heat conduction structure design, high vacuum maintenance system, and perfect multi-stage vacuum pumping process to ensure that the product has better vacuum performance.

3. Based on many years of experience in low-temperature foreign-funded enterprises and extensive research on customer needs, the internal and external pipelines are optimized to provide standard interfaces such as double charging, large-diameter pressure increase, overflow, and venting. Ensure stable gas pressure and flow under the conditions.

4. The connections between the pipelines are welded and card connected, which reduces the possibility of medium leakage, and is safer to use and easier to maintain.

5. The outer cylinder has two types of stainless steel and carbon steel paint to choose, to meet the appearance needs of different customers, according to customer requirements, independent design.


Product Parameters

Effective volume
(M3)

Working pressure
(Bar)

Dimension
(mm)

Weight
(Kg)

5

8

Φ2000*5130

3412

10

8

Φ2100*7170

5378

15

8

Φ2500*6912

6415

20

8

Φ2500*8756

8255

30

8

Φ2900*8870

12899

50

8

Φ3100*12058

18960

100

8

Φ3600*15947

34480


10000L 20000L And 30000L Cryogenic Storage Tanks 8-bar 16-bar And 23-bar Tanks10000L 20000L And 30000L Cryogenic Storage Tanks 8-bar 16-bar And 23-bar Tanks10000L 20000L And 30000L Cryogenic Storage Tanks 8-bar 16-bar And 23-bar Tanks

CONVENIENT OPERATION

The upper part of the tank is equipped with a pressure gauge, a differential pressure type level gauge, and a liquid level comparator, providing intuitive information on storage volume and pressure changes. This facilitates user operations for filling and draining, enhancing operational convenience.

COMPREHENSIVE DETECTION SYSTEM

Equipped with a dedicated tank vacuum valve , allowing periodic or on-the-spot vacuum level checks using a vacuum gauge to ensure the safe operation of the tank.
