80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank
Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
CHINA
MOQ :
1
Price :
depend on product
Payment Terms :
MoneyGram,Western Union,T/T,D/P,D/A,L/C
Packaging Details :
wooden box
Item :
cryogenic storage tank
Color :
white
Keywords :
lng storage tank for sale
Package :
Sea or land transportation
Advantage :
Long Service Time
Working Temperature :
-196 - 0 ℃
Working Years Design :
20years
Piping Material :
Stainless steel
Insulation :
vacuum powder
Capacity :
5000 liters
Description

80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank

Product Description

Cryogenic Storage tank is a kind of high-performance vacuum insulated container, which is used to store and transport cryogenic liquid oxygen, nitrogen, argon, carbon dioxide, liquefied natural gas or nitrous oxide. It can be used for road transportation of cryogenic liquid, and also can be used for on-site storage and supply. Long storage time, wide range of applications, can provide up to 9.2 cubic meters per hour continuous flow with a delivery pressure of approximately 100psig (6.9bar/690Kpa).


Product Parameters

Inner tank/outer tank material

S30408/Q345R(CO2inner tank:16MnR)

Operation pressure

0.2/0.8/1.2/1.6/2.8 MPa

Volume (m3)

5

10

15

20

30

50

60

100

150

200

250

Inner tank size (m)

1.4

1.8

1.8

2

2.2

2.5

2.7

3

3.3

3.5

3.6

Outer tank size (m)

1.9

2.3

2.3

2.5

2.7

3

3.2

3.5

3.8

4

4.1

Daily evaporation rate(%/d)o2

0.4

0.36

0.35

0.33

0.29

0.23

0.21

0.16

0.14

0.13

0.12


80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank80L 5 M³ Hydrogen Cryogenic Cylinder Liquid Oxygen Storage tank


Applications:
1.to fill liquid oxygen for medical use, as an equipment for providing LO2;
2.to fill oxygen for the cutting, welding, and heating of metal in industry;
3.to fill liquid argon for argon-arc welding and other protection occasion of argon;
4.to fill liquid nitrogen for the protective use by high nitrogen, and the field of food, pharmaceutical, biotech, superconductionetc.


ABOUT US

Our company is a professional manufactory of large storage tanks, it contains the design, provided steel material and overseas installation. Professional engineers and construction teams, all the tanks are made in accordance with international standards.

The large storage tanks of various specifications and models can be made. We can choose different types and different materials storage tanks according to the properties of the materials.
