5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank
Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
CHINA
MOQ :
1
Price :
depend on product
Payment Terms :
T/T,D/P,D/A,L/C,Western Union,MoneyGram
Packaging Details :
wooden box
Filling Rate :
95%
Advantage :
High Efficiency
Usage :
Storage and transportation of cryogenic liquids
Key Selling Points :
Long Service Life
Working Medium :
LO2,LPG,LNG
Max Working Pressure :
2.16mpa
Pressure Range :
1.5 bar to 30 bar
Machinery Test Report :
Provided
Construction :
Vertical or horizontal type
Water Storage Tank :
Customized water storage tank
Inner Cylinder Material :
S30408
Description

5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank

Product Description

The fully refrigerated vacuum powder insulated storage tank containing LNG. It is composed of an inner container and an outer shell that maintains a vacuum insulation interlayer and has a complete set of safety accessories, instrumentation and systems that meet operating requirements. The thermal insulation method of filling porous particulate thermal insulation material and vacuuming is adopted to realize the storage of LNG under low temperature and normal pressure.

Specification

NO.

Outline Size

Net Weight(KG)

Type

1

Φ1916*5040

3830

Vertical

2

Φ2316*5808

5465

3

Φ2316*7725

7530

4

Φ2416*8922

9375

5

Φ2920*8574

13060

6

Φ3120*1178

19505

7

Φ3020*14465

23935

8

Φ3424*17666

39135

9

Φ3928*19000

59300

10

Φ2920*8580

16020

11

Φ3020*14551

28300

12

Φ3324*18739

45620

13

Φ1916*4572

3950

Horizontal

14

Φ2316*5398

6050

15

Φ2316*7258

7845

16

Φ2416*864546

9480

17

Φ2916*8289

12800

18

Φ2916*12729

19160

19

Φ2916*14929

21760

20

Φ3424*16442

38460

21

Φ3424*5926

44200

22

Φ3824*19426

50945

5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank5 tons 10 Tons 20 ton and 100 ton Cryogenic Liquid Industrial Gas Storage Tank

Where are cryogenic tanks used?

These form part of gas supply systems to be used in a wide range of applications, including metal processing, medical technology, electronics, water treatment, energy generation, and the food industry.
