High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
Specifications
Price :
$36,000/cases 1-9 cases
Payment Terms :
T/T
Supply Ability :
1set 30days
cnc or not :
Normal
machine type :
Punching Machine
slide stroke (mm) :
200
power source :
Pneumatic
place of origin :
Guangdong, China
brand name :
QIAOSEN
voltage :
380V
dimension(l*w*h) :
2315*1400*3670mm
motor power (kw) :
15
model number :
ST-160V
weight (t) :
16
key selling points :
High-Accuracy
warranty :
1 Year
machinery test report :
Provided
video outgoing-inspection :
Provided
core components :
Bearing, Pump, Gear, Motor, PLC, Pressure Vessel, Engine
punching capacity :
160ton
Slider adjustment amount :
200mm
Up platform area :
990*550*90mm
Down platform area :
1200*800*140mm
Slider center to machine distance :
405mm
Platform to floor distance :
900mm
Main motor power :
15*4
Air pressure :
6
Punch dimension(L*W*H) :
2315*1400*3670mm
Punch weight :
16tons
Place of Origin :
China
Brand Name :
QIAOSEN
Certification :
CE / ISO14001
Description
ST-160 Ton V-Type Pneumatic Punching Machine
This 160-ton open single point crank punching machine meets Japanese JIS 1 class standards for safety, energy efficiency, stability, automation, and high precision.
Performance Features
  • High-strength fuselage structure with minimal deformation and high precision
  • OMPI pneumatic dry clutch brake system
  • Slider with 2-corner and 6-sided guides for enhanced stability
  • Slider guide featuring high-frequency quenching and rail grinding process for reduced wear and extended service life
  • Crankshaft made of high-strength alloy 42CrMo (1.3 times stronger than 45 steel)
  • Copper sleeve constructed from tin phosphor bronze ZQSn10-1 (1.5 times stronger than ordinary BC6 brass)
  • Highly sensitive hydraulic overload protection device to protect press and die service life
  • Optional air cushion mat available
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
Technical Specifications
Item Unit ST-160 V Type ST-160 H Type
Punching capability ton 160
Impact force location mm 6 3
Slider strokes per minute SPM 20-50 40-70
Slider length mm 200 90
Max die shut height mm 460 510
Slider adjustment amount mm 110
Up platform area mm 990×550×90
Down platform area mm 1250×800×140
Shank hole mm Ø65
Main motor power kw×p 15×4
Air pressure kg/cm² 6
Punch accuracy grade JIS 1
Slider adjustment device Electric operation
Slider center to machine distance mm 405
Platform to floor distance mm 900
Punch weight ton 16
Punch dimension (L×W×H) mm 2315×1400×3670
Die cushion capacity ton 10
Stroke mm 80
Active area mm² 650×420
Product Configuration
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
Similar Products
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
Company Profile
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
Packaging
High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping High Accuracy C Frame Punch Press 160t Pneumatic Punching Machine for Metal Stamping
Warranty and Service
  • One year warranty for the complete press machine
  • All spare parts available with most components produced in-house
  • Easy access to electrical parts using international famous brands
  • Technical training and consulting via email, phone, or video
  • Engineer dispatch available for service, installation, or training at reasonable additional cost
  • English operation and maintenance manual provided with the press
  • Certificate of conformity included with press delivery
Frequently Asked Questions
Who are we?
Our factory is located in Wuxi, China with a branch company in Dongguan. Established in 2016, we serve customers in Southeast Asia (50%), Middle East (30%), Africa (10%), South Asia (5%), Northern Europe (4%), and Eastern Europe (1%). Our office employs 51-100 people dedicated to manufacturing high-quality punching machines.
Why select us?
We are a high-end quality punching machine manufacturer committed to customer satisfaction. We guarantee that customers will never regret choosing our brand for their industrial needs.
How about your delivery time?
Typically, delivery takes 25 to 40 working days after receiving your advance payment.
Do you provide after-sale service?
Our technical and quality team provides comprehensive support whenever you need assistance.
Can I customize machine colors?
Yes, we can customize machine colors to match your production line requirements.
Can the touch screen language be changed?
Yes, we can configure the touch screen interface in languages such as Spanish, French, and others according to your requirements.
