Specifications
Brand Name :
Tsinlyne0822
Model Number :
Tsin94069000
Certification :
CE/ISO/SGS
Place of Origin :
CHINA
MOQ :
800sqm
Price :
30-45$
Payment Terms :
L/C,T/T
Supply Ability :
2500ton/month
Delivery Time :
10workdays
Packaging Details :
container
Structure Type :
Steel Frame Building
Sustainability :
Eco-friendly
Corrosion Resistance :
High
Material :
Steel
Application :
Industrial/Commercial
Size :
Customized
Description
Quick Assembly via Steel Frame Building Custom Color Matching Energy Sector Facilities
Structure Type
Steel Frame Building
Sustainability
Eco-friendly
Corrosion Resistance
High
Material
Steel
Application
Industrial/Commercial
Size
Customized
Key Components
  • Wall panel: Sandwich panel with color steel two sides and EPS foam filling (width: 1200mm)
  • Column: C style steel, H shape
  • Floor beam: C style steel, 200×40×2.0mm
  • Floor: Light magnesium board (patented)
  • Stair: Metal construction
  • Roof truss: Angle steel
  • Purlin tube metal
  • Roof panel: Corrugated sandwich panel with color steel two sides
  • Door: Aluminum frame with panel same as wall, with lock
Note: Components may vary based on project requirements.
Via Steel Frame Building Custom Color Matching Energy Sector Facilities Via Steel Frame Building Custom Color Matching Energy Sector Facilities
Technical Specifications
Parameter Value
Earthquake resistance 8 fission intensity
Wind pressure <31m/s (about 10 grade)
Roofing snow load <80kg/m²
Roofing live load 50kg/m²
Key Advantages
  • Cost-effective construction with quick installation
  • Factory-controlled quality assurance
  • Large clear spans up to 80 meters
  • Excellent seismic performance due to lightweight design
  • Customizable aesthetic with various color options
  • Durable with lifespan exceeding 50 years
  • Easy to assemble and dismantle with simple tools
  • Completely waterproof construction

Via Steel Frame Building Custom Color Matching Energy Sector Facilities

Design Requirements
For custom design projects, we require the following information:
  • Rain load requirements
  • Live load specifications
  • Snow load calculations
  • Wind load parameters
  • Crane requirements (if applicable)
  • Building dimensions (length, width, height)
Via Steel Frame Building Custom Color Matching Energy Sector Facilities
Material Specifications
Our steel structures utilize high-quality materials including:
  • Primary structural steel: Q345 (S355JR) or Q235 (S235JR)
  • Anti-corrosion treatments: Galvanization or painted finishes
  • Insulation materials: EPS, rock wool, or PU with 50-150mm thickness
  • Roof/wall panels: Corrugated steel sheet (0.2-1.2mm) or sandwich panels
Via Steel Frame Building Custom Color Matching Energy Sector Facilities Via Steel Frame Building Custom Color Matching Energy Sector Facilities
Why Choose Our Steel Structures
  • Exceptional strength-to-weight ratio
  • 50% faster construction than traditional methods
  • 90%+ recycled material content
  • Energy efficient design options
  • Customizable for diverse applications
  • Low maintenance requirements
Via Steel Frame Building Custom Color Matching Energy Sector Facilities Via Steel Frame Building Custom Color Matching Energy Sector Facilities Via Steel Frame Building Custom Color Matching Energy Sector Facilities
Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We operate our own steel structure, steel sheet, and sandwich panel manufacturing facilities.
Q: Can you provide on-site installation service?
A: We offer comprehensive installation guidance including shop drawings, installation diagrams, and video instructions. Our engineers can also provide on-site supervision if required.
Q: What is the typical delivery time?
A: Delivery typically ranges from 25 to 60 days depending on project size and complexity.
Q: How can I get a quotation for my project?
A: Please contact us with your project details for a customized quote and technical consultation.
