15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
Specifications
Brand Name :
COOLNET
Model Number :
CYA, M08，M15
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1set
Price :
1800-30000USD
Payment Terms :
T/T, L/C
Supply Ability :
300 PCS PER MONTG
Delivery Time :
10-25 working days
Packaging Details :
Packed in plywooden case, standard export package
Cooling capacity :
15KW-20KW, 3ton 5ton 10ton
Mounting :
Floor Standing Units
Type :
Air Cooled Unit/Water Cooled Unit/Glycol Cold Unit
Product name :
Precision Air Conditioning Units
Refrigerant :
R22(R407C/R410A)
Application :
Computer Room,Data Center, Libraries, Laboratories,Large Supermarket
Color :
Grey White Black
Power :
3N-380V-50Hz,220v/50hz/60hz
Airflow :
Front flow/Down ward flow
Description

Multiple Optional Cooling Capacity Server Room Air Cooling Units For Precise Environment

Product Introduction

The high-efficiency PAC in the equipment room ensures the cleanliness, temperature and humidity of the equipment room, and effectively reduces the PUE of the equipment room. Cool-smart series has the following characteristics: full intelligent and precise control of constant temperature and humidity, high sensible heat ratio, large air volume, and small enthalpy difference. In addition, Coolnet-smart has a small footprint and low energy consumption, which can meet the environmental control of small and medium-sized computer rooms for professional needs.

Advantages

High Accuracy

• Precise control of humidifier system with a unique dry steam humidification intelligent control unit
High Efficiency
• Large outdoor condenser cooIing circuit design and outdoor speed control fan and condensing pressure automatic adjustment device
High Intelligent
• Standard RS485 communication interface, optional internet interface, support ModBus/TCP and other customized protocols.
 15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
15KW-20KW Cooling Capacity Precision Air Conditioning Unit with Floor Standing Mounting and High Sensible Heat Ratio for Server Rooms
Fan
• Backward centrifugal fan
• Efficient, improve the energy efficiency ratio of the whole machine
• Low noise
• The air volume is more than 35% higher than the air volume of the comfort air conditioner with the same cooling capacity
Humidifier
• Direct electrode humidifier
• Fuzzy logic control humidification program
• Removable for cleaning
• Microcomputer-controlled automatic flushing cycle process
• Low noise water supply solenoid valve to ensure quietness
• Automatic failure prevention during operation

Product Specification

Model M04 M06 M08 M13 M16 M20
Power Supply 220V1Ph-50Hz 380V3Ph-50Hz
Air discharge Up Front/Down
Technical Data Sheet
AC Fan Total cooling capacity-KW 4.2 6.4 7.5 12.5 16.8 20.2
Sensible cooling capacity-KW 3.9 5.8 6.9 11.3 15.3 18.3
Unit FLA-A(heating, humidifying type) 20.0 25.0 16.8 22.0 23.5 28.6
Compressor Quantity 1
Fan Quantity 1
Air Volume-m3/h 1600 1900 2300 3600 5100 6500
Heater Capacity-KW 3.0 3.0 6.0 6.0 6.0 6.0
Humidification-kg/h 3 3 3 3 6 6
Power of humidifier-KW 2.3 2.3 2.3 2.3 4.5 4.5
Outdoor Condenser
Model SCA020 SCA020 SCA030 SCA030 SCA050 SCA050
Standard unit operating temperature range-℃ -15-45℃
Low Temperature Components Operating Temperature Range-℃ -40-45℃

Application

  • Small-Medium size computer room
  • Communication base
  • Rail road, Army, Broadcast base
  • Power room, substation
  • Monitoring room, Power distribution room, Battery room
  • High precision lab, Test room, Inspection room, Measuring room
  • Industrial control room, Precision workshop
  • Archives,Store room, Museum, Wine cellar
