Specifications
Place of Origin :
Henan, China
Brand Name :
Aobest
Model Number :
multi conductor cables
Insulation Material :
PVC
Type :
LOW VOLTAGE
Application :
Industrial
Conductor Material :
Copper
Jacket :
PVC
Size :
1.5 mm2
Product name :
high quality multiconductor cable 1.5 mm2
Certificate :
ISO9001
Standard :
BS IEC ASTM DIN
Conductor :
Bare Copper
Color :
Customized
Insulation :
pvc
Core :
Multi-core
Name :
multi conductor cable
MOQ :
20 kilometers
Price :
$700.00 - $1,650.00/kilometers
Description

Best Choice Multiconductor Cable -- PVC Copper Shielded Braided

Application

Used as power and connecting cables in mechanical engineering for tooling machinery, control unit,

production lines, transportation equipment, conveyor and assembly lines as well as in plant construction

under the circumstance that the rated voltage is up to 450/750V AC.

Character and Relevant Parameters

1. Long-term service temperature of the cable conductor: 70 0C

2. Rated voltage: 450/750V

3. Cable lying temperature ≥0 0C

4. Cores: 2, 3, 4, 5, 6,7, 8, 10, 12, 14, 16, 19, 24, 27, 30, 37, 44, 48, 52, 61

5. Minimun bending radius:

Non armored ≥ out diameter of cable 6 times

Armored layer or copper tape shielded ≥ outer diameter of cable 12 times

Shielded layer soft cable ≥ outer diameter of cable 6 times

PVC Insulated Control Cable Parameter (Example)

Type

Name

Section Area(mm2)

No. of Core

KVV

 Copper Conductor, PVC Insulated and Sheathed control cable

0.75 1.0 1.5 2.5

2-8 10 12 14 16 19 24 27 30 37

4.0 6.0

2-8 10 12 14

KVVP

Copper Conductor, PVC Insulated and Sheathed, Copper-braid Screened Control Cable

0.75 1.0 1.5 2.5

2-8 10 12 14 16 19 24 27 30 37

4.0 6.0

2-8 10 12 14

KVVP2

Copper Conductor, PVC Insulated and Sheathed, Copper-tape Screened Control Cable

0.75 1.0 1.5 2.5

2-8 10 12 14 16 19 24 27 30 37

4.0 6.0

2-8 10 12 14

KVVP2-22

Copper Conductor, PVC Insulated and Sheathed, Copper-tape Screened Steel-tape armored Control Cable

0.75 1.0 1.5 2.5

2-8 10 12 14 16 19 24 27 30 37

4.0 6.0

2-8 10 12 14

KVV22

Copper Conductor, PVC Insulated and Sheathed, Steel-tape armored Control Cable

0.75 1.0 1.5 2.5

2-8 10 12 14 16 19 24 27 30 37

4.0 6.0

2-8 10 12 14

KVVR

Copper Conductor, PVC Insulated and Sheathed, Flexible Control Cable

0.75 1.0 1.5 2.5

2-8 10 12 14 16 19 24 27 30 37

4.0 6.0

2-8 10 12 14

KVVRP

Copper Conductor, PVC Insulated and Sheathed, Braiding shielded Flexible Control Cable

0.75 1.0 1.5 2.5

2-8 10 12 14 16 19 24 27 30 37

4.0 6.0

2-8 10 12 14

We also produce:

flame-retardant control cable, XLPE insulated control cable, XLPE insulated flame-retardant control cable, low smoke halogen free flame-retardant control cable etc.
