ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
ROHS/CCC/ISO9001 2008 Certified 4 Pair 5 Pair Instrumentation Cable with PVC Jacket
Specifications
Place of Origin :
Henan, China
Brand Name :
aobest
Model Number :
KVV
Shielding :
Foil
Conductor Material :
Copper
Jacket :
PVC
Insulation Material :
PVC
Product Name :
Instrument cable
color :
red/yellow/blue/black/orange
type :
instrumntation cable
Certificate :
ROHS/CCC/ISO9001:2008
Standard :
IEC BS ASTM DIN GB9330-1998
Package :
Wodden Reel
Packaging Details :
wooden drum or steel wooden drum or as your special requirement
Port :
Qingdao or Shanghai
Supply Ability :
500 Kilometer/Kilometers per Week
Price :
$1,000.00/kilometers 1-1999 kilometers
Description
HOT SALE! CHINA top quality 4 pair 5 pair instrumentation cable
Specifications

copper conductor PVC/PE/XLPE insulated PVC sheathed control cable.

Detailed Product Description

1. Standard

The control cable can be produced according to the standard GB9330-1988,IEC,DIN,BS,and the factory can also manufacture the cables in accordance with other standards.

2.Scope of Application

The control cable are suitable for the wiring of electrical controlling equipments and instrument,monitoring and controlling return circuit,electrical protection and measurement in power distribution unit under the circumstance that the rated voltage is up to 450/750V AC.

3.Type& Specification

Type

Name

Section Area(mm2)

No. of Core

Application Site

KVV

Copper Conductor,PVC Insulated and Sheathed Control Cable

0.75 1.0 1.5 2.5

2-16

Permanent installation indoors,in cable ditches or pipes

4 6

2-14

10

2-10

KVVP

Copper Conductor,PVC Insulated and Sheathed,Braiding Shielded Control Cable

0.75 1.0 1.5 2.5

2-61

Permanent installation indoors,in cable ditches or pipes where shielding is required

4 6

2-14

10

2-10

KVVP2

Copper Conductor,PVC Insulated and Sheathed,Copper-tape Screened Control Cable

0.75 1.0 1.5 2.5

4-10

Permanent installation indoors,in cable ditches or pipes where shielding is required

4 6

7-61

10

4-10

KVV22

Copper Conductor,PVC Insulated and Sheathed,Steel tape Armored Control Cable

0.75 1.0 1.5 2.5

7-61

Permanent installation indoors,in cable ditches,Be able to withstand stronger external mechanical force

4 6

4-14

10

4-14

KVVR

Copper Conductor,PVC Insulated and Sheathed,Flexible Control Cable

0.5-2.5

4-61

Installation indoors where flexibility and movability are required

KVVRP

Copper Conductor,PVC Insulated and Sheathed,Braiding shielded Flexible Control Cable

0.5 0.75 1.0

4-61

Installation indoors where flexibility shielding and movability are required

1.5 2.5

4-48

KYJV

Copper Conductor,XLPE Insulated and PVC Sheathed Control Cable

0.75 1.0 1.5 2.5

2-16

Permanent installation indoors,in cable ditches or pipes

4 6

2-14

10

2-10

KYJVP

Copper Conductor,XLPE Insulated,Braiding Shielded,PVC Sheathed Control Cable

0.75 1.0 1.5 2.5

2-61

Permanent installation indoors,in cable ditches or pipes where shielding is required

4 6

2-14

10

2-10

KYJV22

Copper Conductor,XLPE Insulated,Steel-tape Armoured,PVC Sheathed Control Cable

0.75 1.0 1.5 2.5

7-61

Permanent installation indoors,in cable ditches,pipes or underground Be cable to with stand stronger external mechanical force

4 6

4-14

10

4-10

KYJVP2

Copper Conductor,XLPE Insulated,Copper tape Screened,PVC Sheathed Control Cable

0.75 1.0 1.5 2.5

7-61

Permanent installation indoors,in cable ditches or pipes where shielding is required

4 6

4-14

10

4-10

KYJVR

Copper Conductor,XLPE Insulated,PVC Sheathed Flexible Control Cable

0.5-2.5

4-61

Installation indoors where flexibility and movability are required

KYJVRP

Copper Conductor,XLPE Insulated,Braiding Shielded,PVC Sheathed Flexible Control Cable

0.5 0.75 1.0

4-61

1.5 2.5

4-48

Installation indoors where flexibility shielding and movability are required

We will provide you with High quality and reasonable price wire. welcome your trial order.
