Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
Specifications
Place of Origin :
Henan, China
Brand Name :
Aobest
Model Number :
CU/PVC/PVC control cable
Application :
Construction
Conductor Material :
Copper or Aluminum
Jacket :
PVC
Insulation Material :
PVC or XLPE
Color :
Black
Certification :
CCC, ISO9001
Product Name :
KVVP non-armored copper wire braid shield control cable
Certificate :
ISO9001
Standard :
IEC60502
Packing :
Wooden Drum
MOQ :
1000 meters
Price :
$1.00 - $6.00/meters
Description
PVC Insulated SWA armored control cable
1. Characteristics and Applications of the Products:

Plastic insulated control cable is used to connect electrical equipments. It applies to controlling, monitoring and protective system with A.C. rated voltage U0 /U up to and including 450/750v.

The main features of the flame retardant PVCcontrol cable is hard to get fire or that the continuous buring of cables is very limited when it is on fire .It applies to the places with special demands of flame retardant property.

Fire resistant cable can operate normally for some time when it is burning except that is transmit electrical power under normal condition.It is used in the places necessary to resist fire.

2.Operating characteristics:

(1)The long-time permissible operating temperature is 70oC;

The ambient temperature under installation should not go below 0oC.

(2)a. for non-armoured cable and flexible shielded cable, the bending radius should not be less than 6 times the outer diameter;

b. for armoured or copper-tape shielded cable, the bending radius should not be less than 12 times the outer diameter;

Model

Description

Application

KVV

copper conductor, PVC insulated, PVC sheathed, control cable

Suitable for being laid indoors, in cable trench, pipelines or other specific occasions.

KVVP

copper conductor, PVC insulated, PVC sheathed, braided, shielded, control cable

Suitable for being laid indoors, in cable trench, pipelines or other specific occasions that demands shielding.

KVVP2

copper conductor, PVC insulated, PVC sheathed, copper-tape shielded, control cable

KVV22

copper conductor, PVC insulated, PVC sheathed, steel-tape armored, control cable

Suitable for being laid indoors, in cable trench and pipelines, directly burial or other specific occasions with a relatively large capacity for mechanical stretching force.

KVV32

copper conductor, PVC insulated, PVC sheathed, thin steel wire-armored, control cable

Suitable for being laid indoors, in cable trench, pipelines, silo or other specific occasions that demands shielding.

KVVR

copper conductor, PVC insulated, PVC sheathed, flexible, control cable

Suitable for being laid indoors and places that demands moving cables with flexibility.

KVVRP

copper conductor, PVC insulated, PVC sheathed, braided shielded, flexible, control cable

Suitable for being laid indoors and shielded places that demands moving cables with flexibility.

Insulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 StandardInsulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 StandardInsulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 StandardInsulated Copper or Aluminum Conductor Braided Shield Control Cable for IEC60502 Standard
