Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Top Quality SWA Cable XLPE insulated power Cable
Specifications
Place of Origin :
Henan, China
Brand Name :
Aobest
Model Number :
cu pvc swa pvc cable
Insulation Material :
PVC
Type :
LOW VOLTAGE
Application :
Construction
Conductor Material :
Copper
Jacket :
PVC
Color :
Various
Product name :
high quality YJV22 cable
Certificate :
ISO9001/ISO14001 /OHSAS18001/CCC
Standard :
BS IEC ASTM DIN
Conductor :
copper
Insulation :
pvc
Core :
Multi-core
Name :
VV22 cable
Packaging Details :
export standard steel-wooden drum or as your request
Port :
Qingdao or Shanghai
Supply Ability :
3000 Kilometer/Kilometers per Month
MOQ :
200 feet
Price :
$0.05 - $0.90/feet
Description

SWA Cable YJV YJV22 YJV32 VV VV22 VV32 Cable

Product Description:

1. Conductors: copper or aluminum.

2. Both armored and non-armored type power cables are available.

3. Voltage rating: 0.6/1kV 3.6/6kV 6/10kV 8.7/15kV 26/35kV.

4. PVC or PE sheathed.

5. Number of cable cores: one core (Single core),two cores(Double cores),three cores,

Four cores (Four Equal-section-area cores or three equal-section-area cores and one smaller section area neutral core),

Five cores (Five equal-area cores or three equal-section-area cores and two smaller section area neutral cores).

Type and description:

Type

Description

Application

Cu Core

Al Core

YJV

ZR-YJV

YJLV

ZR-YJLV

Cu(Al)Core, XLPE Insulated, PVC Sheathed Power Cable

Cu(Al)Core, XLPE Insulated, PVC Sheathed flame- retardant Power Cable

Can be laid in indoor, outdoor, tunnels, cable channels, reinforced concrete pipelines and loose soil. Cable should not bear outer mechanic force, but can bear a certain tractional force.

YJV22

ZR-YJV22

YJLV22

ZR-YJLV22

Cu(Al)Core, XLPE Insulated, Steel Tape Armored and PVC Sheathed Power Cable

Cu(Al)Core, XLPE Insulated, Steel Tape Armored and PVC Sheathed flame- retardant Power Cable

Laid underground. Cable can bear outer mechanic force, but should not bear large tractional force.

YJV32

ZR-YJV32

YJLV32

ZR-YJLV32

Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed Power Cable

Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed flame- retardant Power Cable

Laid in indoor, tunnels and mines. Cable can bear outer mechanic force and fairly large tractional force.

YJV42

ZR-YJV42

YJLV42

ZR-YJLV42

Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed Power Cable

Cu(Al)Core, XLPE Insulated, Steel Wire Armored and PVC Sheathed flame- retardant Power Cable

Can be laid in vertical section, indoor, tunnels and mines. Cable can bear outer mechanic force and very large tractional force.

Description:

Rate
Voltage(kv)
Sectional
Area(mm 2 )
No.of Core
1st class 0.6/1 1.8/3 3.6/6 6/10 8.7/15 12/20 18/30 21/35
2nd class 1/1 3/3 6/6 8.7/10 12/15 18/20 - 26/35
1 Core 1.5-800 25-800 25-1200 25-1200 35-1200 50-1200 50-1200 50-1200
2 Core 1.5-185 25-185
3 Core 1.5-400 25-400 25-400 25-400 35-400 50-400 50-400 50-400
4 Core 2.5-400 25-400
5 Core 2.5-400 25-400

Top Quality SWA Cable XLPE insulated power Cable Top Quality SWA Cable XLPE insulated power Cable
