Specifications
Place of Origin :
Henan, China
Brand Name :
Aobest
Model Number :
BS 7870 NYCY
Insulation Material :
PVC/PE/XLPE
Type :
LOW VOLTAGE
Application :
Energy Supply
Conductor Material :
Copper or Aluminum
Jacket :
PVC/PE/XLPE
Product name :
Concentric Cable
Certificate :
ISO9001/ISO14001 /OHSAS18001/CCC
Standard :
BS IEC ASTM DIN
Color :
Customized
Insulation :
XLPE PE PVC
Sheath :
Flame Retardant PVC
Rated voltage :
600/1000V
Package :
Wooden Drum
MOQ :
500 meters
Price :
$1.20/meters
Description

Concentric Split single phase service cable, 4mm to 35mm

Plain annealed stranded copper phase conductor,

XLPE insulated surrounded by a concentric layer of plain annealed solid copper neutral conductors.

XLPE insulated and plain annealed solid strand bare copper earth conductors,

PVC outer sheath. Black.

600/1000 volts

grade to BS7870.

Choose a cable type

CCC Code Conductor size
(MM2)		 Stranding Cores Weight
(KG/KM)		 Overall
Diameter (MM)		 Gland
Size		 Cleat Trefoil
Cleat
4SPLITCON 4 7/0.85 1 206 9.6 20S - -
6SPLITCON 6 7/1.04 1 281 11.4 20 - -
10SPLITCON 10 7/1.35 1 394 12.7 20 - -
16SPLITCON 16 7/1.70 1 583 14.6 25 - -
25SPLITCON 25 *7/2.14 1 843 18.7 32 - -
35SPLITCON 35 7/2.52 1 1300 23 40 - -

Conductor identification :
Brown live/Blue neutral.

Should not be installed at temperatures below 0oc or above + 60oc.

Also available in Violet outer sheath in 6mm, 10mm, 16mm & 25mm.

* Stranding of neutral is the same as phase conductor except 25 sq mm which has 11 x 1.70mm.Best Price China PVC Concentric Cable BS7870 Low Voltage Insulated Type

Best Price China PVC Concentric Cable BS7870 Low Voltage Insulated TypeBest Price China PVC Concentric Cable BS7870 Low Voltage Insulated Type

Best Price China PVC Concentric Cable BS7870 Low Voltage Insulated Type

Please contact me freely; maybe I’ll give you a big surprise. ^_^
