3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
Specifications
Brand Name :
HUAN NENG
Model Number :
HP188F/P
Certification :
ISO,CCC
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
Car model :
Universal
Engine code :
unknown
Feature :
Stable Continuous Operation
Description

Cheap Convenient Max7.2KW Gasoline Stable continuous operation Engine

4 stroke gasoline engine

Advantage,

1. Economical, low fuel consumption, stable continuous operation.

2. The brush changer is ignited with electricity, which is convenient for maintenance

3. Standard calibration voltmeter, easy to use.

The Details of this diesel engine

Model HN173FB HN178F HN186FA HN188FA HN192F HN195F
type Single-red,four-stroke,air-cooled,vertical' direct original type
Combustion system Direct Injection
The cylinder diameter x Trip 73x59 78x62 86x72 88x75 92x75 95x75
Displacement 0.247 0.296 0.418 0.45€ 0.499 0.532
Compression Ratio 20:1 20:1 19:1 20:1 19:1 19:1
(Kw/rpm ) Rated Power/speed 3.2/3000,3.6/3600 3.7/3000.4.0/3600 5.8/3000,6.6/3600 6.6/3000.7.5/3600 7.5/3000,8.2/3600 8.5/3000,9.2/3600
(Hp/rpm ) Max Power/Speed 4.3/3000,4.8/3600 5.0/3000,5.5/3600 7.9/3000,9.0/3600 9.0/3000,10.2/3600 10.2/3000,11.2/3600 10.2/3000,11.2/3600
Rated Speed 3000/3600 3000/3600 3000/3600 3000/3600 3000/3600 3000/3600
Start The Way F: Manual start e: electric start
Tank Volume 2.5 3.5 5.5 5.5 5.5 5.5
(L ) Lubricating Oil Capacity 0.75 1.1 1.65 1.65 1.65 1.65
(L/H) Fuel Consumption w1.2 W1.41 W2.15 w2 w2 w2
Fuel Brand :0# (§) , -10# () Diesel: 0 x 10 (summer), - 10 x 10 (winter)
Lubncating Oil Brand Sae10w30 (above CD level)
LXWXH ( mm ) Dimensions 332x376x415 385x420x450 420x440x495 420x440x495 420x440x495 420x440x495
The Net Weight Manual start: 28 Manual start: 33 Electric start: 32 Electric start: 38 53 Manual start: 47 Manual start: 48 Electric start: 53 Electric start: 53 Manual start: 50 Electric start: 55 Manual start: 50 Electric start: 55

3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW3000rpm 4 Stroke Single Cylinder Petrol Engine Cycle 7.2KW
