Specifications
Brand Name :
HUAN NENG
Model Number :
BL125000CJ
Certification :
CE, ISO 14001, ISO 9001
Place of Origin :
Chongqing, China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
20000 sets per month
Delivery Time :
7-15 work days
Packaging Details :
Carton box packing for each set
rated power :
AVR voltage automatic adjustment
Rated speed :
11 KW
Rated frequency :
50Hz
weight :
240kg
Continuous working time :
8h
Caster attachment :
Standard
battery capacity :
12V- 36AH maintenance free battery
Product name :
silent industrial generator
Engine :
with cummins engine
Description

Maximum 11KW Rated 10KW V-Shaped Twin-Cylinder Four-Stroke Water-Cooled Direct Injection Silent Diesel Generator

10KW Silent Diesel Generator

THE ADVANTAGE :

Powerful commercial grade V-twin engine with low vibration and emission, more durable, stable, reliable and powerful.

- Precise ignition control, intelligent speed regulation according to the load, more than fuel saving, economic and efficient.

- Short-circuit protection is more in place, safe and reliable and more effective.

- Humanized design concept, integrated panel operation, clear and easy to operate.

- Carefully designed commercial high-power generator, covering 110-415V, single/three-phase, minimizing maintenance and servicing costs.

- Equipped with safety protection system and large oil tank to ensure long time operation, up to 7 hours continuous operation at rated power.

ADD: if you want to know more details, please contact us.

Details

dynamo Unit Type BL12500CJ
Excitation method AVR voltage automatic adjustment
maximum output power 11KW
Rated output power 10KW
Rated voltage 230V 230V/400V
Maximum current 47.8A 15.9A per phase
Rated frequency 50HZ
Phase single phase three phase
power factor cos 1.00 0.8
Insulation class F级
engine engine model EV80/292
Rigid x stroke 86*72mm/92*75mm
Displacement 840cc/997cc
fuel consumption rate 270g/KW.h
ignition method compression ignition
engine type V-twin/in-line twin, four-stroke, water-cooled, direct injection
fuel type Diesel: 0# (summer)-10# (winter)-35# (severe cold)
oil quantity 1.7L/2.6L
Start method Electric start
Attachment configuration fuel capacity 25L
battery capacity 12V-36AH maintenance-free battery
oil alarm yes
fuel indicator yes
control panel digital display
Caster attachment Standard
other noise 70Dba/7m
Continuous working time 8h
Dimensions 1160*660*900
weight 240KG
